Peerless-AV OSUA771PU – Ultra Slim Articulating Wall Mount 55-77in OLED/QLED

What is the Peerless-AV OSUA771PU ultra slim articulating wall mount?

The Peerless-AV OSUA771PU is a DesignerSeries ultra slim articulating wall mount purpose-built for 55" to 77" OLED and QLED displays. It is a full-motion TV wall mount designed around thin-panel geometry, using dual articulating arms so an OLED display can swing out, extend, and swivel without stressing the panel's slim chassis. Integrators spec the OSUA771PU for executive offices, boardrooms, and premium hospitality spaces where an ultra-thin OLED wall mount needs to sit nearly flush to the wall in its retracted position while still offering full articulation for viewing angle adjustment. It carries up to 125 lb and supports VESA patterns from 200 x 100mm to 400 x 400mm.

What does the Peerless-AV OSUA771PU do?

The OSUA771PU's dual-arm articulating design lets a 55"-77" OLED or QLED display retract to 2.87" from the wall for a low-profile look, then extend out to 25.87" and swivel ±72.5° for viewing angle adjustment from off-axis seating. Tilt runs +10° to -3°, with ±5° roll for post-installation leveling, giving installers fine control over final display positioning without shimming the wall plate. The mount's gloss black fused epoxy finish is scratch-resistant, which matters on a full-motion OLED mount that gets adjusted regularly in an executive or hospitality setting. Integrated cable management routes HDMI, network, and power cabling through the arm assembly rather than leaving cords exposed, which keeps the installation presentable in client-facing rooms. Because the arm geometry is engineered specifically for thin-panel OLED and QLED displays, it avoids the flex and stress points that a generic full-motion mount can introduce on a slim chassis. The OSUA771PU installs to wood studs, concrete, cinder block, or breeze block, and is UL Listed and RoHS compliant, covering the certification requirements most commercial and institutional buyers ask for.

Key Features

• Dual articulating arm design — engineered specifically for thin-panel OLED/QLED displays, reducing chassis stress compared to generic full-motion mounts.
• Ultra-low profile retracted position — sits just 2.87" from the wall when closed for a near-flush appearance.
• 25.87" maximum extension — pulls the display well off the wall for optimal viewing angle in wide rooms.
• ±72.5° swivel and +10°/-3° tilt — full-motion adjustment for off-axis seating and glare control.
• ±5° roll leveling — corrects for uneven wall conditions after installation.
• 125 lb weight capacity — rated for large-format OLED and QLED panels up to 77".
• Integrated cable management — keeps HDMI, network, and power runs concealed through the arm.
• 5-year limited warranty — with UL Listing and RoHS compliance.

Typical Applications

• Boardrooms
• Executive/commercial meeting spaces
• Hospitality spaces
• Multi-purpose rooms

Technical Specifications

Frequently Asked Questions

Is the OSUA771PU compatible with standard LCD displays or only OLED/QLED panels?
It is engineered specifically for the thin chassis geometry of 55"-77" OLED and QLED displays. Standard LCD displays within the VESA and weight range will physically fit, but the mount's arm design is optimized for slim-panel models.

How far can the display extend from the wall?
The arm extends from 2.87" in the retracted position to a maximum of 25.87" from the wall, allowing significant reach for wide-room viewing angles.

What wall surfaces does the OSUA771PU support?
It installs to wood studs, poured concrete, cinder block, or breeze block with the included hardware; assembly is required.

Does it support portrait orientation for digital signage?
The mount is designed primarily for landscape orientation on OLED/QLED panels; confirm orientation requirements with your display manufacturer before specifying for portrait signage.

What is the weight capacity and VESA range?
Up to 125 lb, with VESA compatibility from 200 x 100mm to 400 x 400mm.

What is the warranty on the OSUA771PU?
Peerless-AV backs the mount with a 5-year limited warranty, and it is UL Listed and RoHS compliant.

Can Creation Networks integrate this mount into a full boardroom AV system?
Yes. Creation Networks pairs mounting hardware like the OSUA771PU with display procurement, cabling, and AV system design as part of a full project scope. Browse the full Peerless-AV articulating mount lineup for comparable options.
