Peerless-AV DS-MBZ947L-2X1 – 2x1 Menu Board Ceiling Mount

Product Overview

The Peerless-AV DS-MBZ947L-2X1 is a SmartMount digital menu board ceiling mount engineered for quick-service restaurants and high-traffic retail. It suspends two 46" to 48" displays in a 2x1 landscape configuration from a single ceiling frame, supporting up to 200 lb (90.72 kg). With tool-less 8-point adjustment and Increlok tilt, integrators can align both screens on the same plane for a continuous menu board surface.

Product Description

This ceiling-mounted menu board solution is designed to create a clean, aligned digital signage surface where wall space is unavailable or impractical. Connecting wall plates form a continuous mounting surface, while tool-less four-corner depth adjustment lets the installer bring all displays onto the same plane without hand tools. Horizontal adjustment closes gaps between panels for a tight, professional menu board appearance, and the Increlok tilt option locks every display to a matching angle from 0 to 15 degrees. Quick connect adaptor rails engage the support frame with an auto-latch, speeding installation and giving the integrator confidence the displays are secure. Included security hardware deters tampering and theft in customer-facing environments. The mount ships ready for VESA patterns from 100 x 100 up to 600 x 400 mm. For related fixtures, see the Peerless-AV collection at Creation Networks.

Key Features

• 2x1 Landscape Configuration — Mounts two 46" to 48" displays side by side from a single ceiling frame for a unified menu board.
• Tool-less 8-Point Adjustment — Four-corner depth and micro-adjustment bring all displays onto the same plane without hand tools.
• Increlok Tilt — Continuous and fixed tilt from 0 to 15 degrees locks every display to a matching angle for consistent alignment.
• Quick Connect Adaptor Rails — Auto-latching rails engage the support frame to speed installation and secure each display.
• Horizontal Adjustment — Lets the installer close gaps between panels for a continuous, professional signage surface.
• Security Hardware — Included tamper-resistant hardware deters theft in public, customer-facing locations.
• 200 lb Load Capacity — Supports a combined display load up to 200 lb (90.72 kg).

Typical Applications

• Quick-service and fast-casual restaurants
• Retail point-of-sale and checkout areas
• Transportation hubs and wayfinding
• Hospitality and concession environments

Technical Specifications

Frequently Asked Questions

How many displays does the DS-MBZ947L-2X1 hold?
It mounts two 46" to 48" displays in a 2x1 landscape configuration from a single ceiling frame.

What is the maximum load capacity?
The mount supports a combined display load up to 200 lb (90.72 kg).

How are the displays aligned?
Tool-less 8-point adjustment, horizontal adjustment, and Increlok tilt let the installer align all panels on the same plane and angle without hand tools.

What VESA patterns are supported?
The mount accommodates VESA patterns from 100 x 100 up to 600 x 400 mm.

Is it TAA compliant?
Yes. The DS-MBZ947L-2X1 is TAA compliant and UL listed, supporting government and institutional procurement.

Does it include security hardware?
Yes. Tamper-resistant security hardware is included to deter theft in customer-facing locations.

What warranty applies?
Peerless-AV provides a 5-year limited warranty.
