Peerless-AV PLAV60 – Articulating Wall Arm, Vertical Adjust

Product Overview

The Peerless-AV PLAV60 is a dedicated articulating wall arm with vertical adjustment for 37" to 95" displays. Engineered for large commercial screens, it carries up to 175 lb and combines wide articulation with plus or minus 1" of behind-display vertical adjustment for precise positioning. It suits boardrooms, auditoriums, and public displays where a single large screen must extend, swivel, and sit at exactly the right height. As a dedicated model, it pairs with a display-specific adaptor purchased separately.

Product Description

The PLAV60 is an all-steel articulating wall arm built to position large displays up to 95" and 175 lb in lobbies, boardrooms, hotel rooms, public displays, and home theaters. Self-lubricating bushings allow the arms to articulate smoothly so the display can be extended, swiveled, and tilted for optimal viewing, while three pivot points deliver up to 180 degrees of swivel. The arm extends up to 31.20" (792mm) from the wall and includes +10/-5 degrees of tilt plus or minus 7 degrees of roll for glare control and leveling. What sets the PLAV variant apart is plus or minus 1" (24mm) of vertical adjustment located within reach behind the display, allowing fine height alignment after installation, which is useful in video wall edge alignment and multi-room standardization. An included mesh cord sheath and cable ties keep cabling managed as the arm moves. As a dedicated model, the PLAV60 mounts to displays using a display-specific adaptor (sold separately). Explore comparable articulating arms in the Peerless-AV collection on Creation Networks.

Key Features

• 175 lb Load Capacity — All-steel construction supports large displays from 37" to 95" weighing up to 175 lb.
• Behind-Display Vertical Adjustment — Plus or minus 1" (24mm) of vertical travel within reach behind the display allows precise height alignment after mounting.
• Up to 180 Degree Swivel — Three pivot points provide a wide range of viewing angles.
• Extends Over 31 Inches — The arm extends up to 31.20" (792mm) from the wall to bring the display into the room.
• Tilt and Roll — Offers +10/-5 degrees of tilt and plus or minus 7 degrees of roll for glare control and leveling.
• Self-Lubricating Bushings — Deliver smooth, controlled articulation across the arm's full travel.
• Integrated Cable Management — Includes a mesh cord sheath and cable ties for organized cabling.

Typical Applications

• Boardrooms and conference rooms
• Auditoriums and house of worship spaces
• Corporate lobbies and public displays
• Hospitality and multi-purpose rooms
• Training rooms and all-hands spaces

Technical Specifications

Frequently Asked Questions

What displays does the PLAV60 support?
It supports 37" to 95" displays weighing up to 175 lb.

What is the difference between PLAV60 and a standard PLA arm?
The PLAV variant adds plus or minus 1" (24mm) of vertical adjustment located within reach behind the display for precise height alignment after installation.

Does it include a display adaptor?
This is a dedicated model and requires a display-specific adaptor, which is purchased separately to match your screen.

How far does the arm extend and swivel?
The arm extends up to 31.20" (792mm) from the wall and provides up to 180 degrees of swivel across three pivot points.

Can I manage cables on this mount?
Yes. A mesh cord sheath and cable ties are included to keep cabling neat through the arm's range of motion.

What warranty is included?
The PLAV60 carries a Peerless-AV limited 5-year warranty.
