AEC0305-W – Peerless-AV Adjustable Extension Column 3–5’ White
The Peerless-AV AEC0305-W is a white solid steel adjustable extension column providing 3 to 5 feet of height adjustment in 1-inch increments, designed for use with projector and flat panel ceiling mount applications where white hardware is required for a consistent finished appearance.
Product Description
The AEC0305-W extension column is manufactured in the United States from high-grade solid steel, providing a load capacity of up to 900 lb to accommodate demanding commercial ceiling mount applications including large projectors, flat panel displays, and multi-component mounting systems. The 1.5-inch diameter NPT pipe is threaded at both ends for secure connection to compatible ceiling mount hardware and is designed to carry interior cable routing, keeping wiring concealed within the column.
Height adjustment in 1-inch (25 mm) increments allows the installer to dial in the precise ceiling drop without requiring full disassembly of the mounting system. The column is specifically engineered to support adjustment while assembled, a practical feature in installations where fine-tuning is needed after initial mounting. Set screws are included for quick and reliable position locking once the desired height is achieved.
The white finish makes the AEC0305-W the direct choice for installations in white-ceiling environments such as classrooms, boardrooms, and retail spaces where a black column would be visually inconsistent. It is the white-finish counterpart to standard black extension columns in the Peerless-AV line.
Key Features
- Adjustable height range of 3 to 5 feet (91 to 152 cm) in 1-inch (25 mm) increments.
- Supports loads up to 900 lb for heavy-duty projector and display ceiling mount applications.
- High-grade solid steel construction for long-term structural performance.
- 1.5" diameter NPT pipe threaded at both ends for secure ceiling mount connections.
- Interior cable routing conceals wiring within the column for a clean installation.
- Designed for height adjustment without requiring full disassembly of the mounting system.
- Includes set screws for fast and reliable height position locking.
- White finish for visual consistency in white-ceiling environments.
- Manufactured in the United States.
Technical Specifications
| Specification | Value |
|---|---|
| Model Number | AEC0305-W |
| Adjustable Height Range | 3’ – 5’ (91 – 152 cm) |
| Height Adjustment Increment | 1" (25 mm) |
| Maximum Load Capacity | 900 lb |
| Pipe Diameter | 1.5" NPT |
| Pipe Threading | Both ends |
| Cable Management | Interior routing |
| Color | White |
| Material | Solid Steel |
| Country of Origin | United States |
