Peerless-AV KIL655 – 55" Landscape Wall Kiosk Enclosure
Product Overview
The Peerless-AV KIL655 is a landscape wall kiosk enclosure that houses 55" ultra-thin displays for digital signage, wayfinding, and interactive content. With an ADA-compliant 3.97" profile, this on-wall kiosk enclosure delivers a clean, recessed look while leaving room inside for media players, fans, and other electronics. It is a practical choice for integrators deploying commercial digital signage in high-traffic public environments.
Product Description
The KIL655 ships pre-assembled to simplify installation of the complete signage solution. A hinged, locking top frame opens for fast access to the display and internal components, while security locks help prevent unintended access in unattended deployments. Eight-way tool-less adjustment lets installers position the display flush within the kiosk window, and a pull-out mount makes the panel easy to service after install. Thermostat-controlled circulation fans maintain proper airflow inside the enclosure to protect the electronics during continuous operation. The enclosure accepts mounting patterns from 200 x 200mm up to 600 x 400mm and supports displays up to 2" thick. For portrait orientation or other sizes, see the Peerless-AV collection at Creation Networks.
Key Features
- Fits 55" Displays — Houses 55" ultra-thin commercial displays up to 2" (50mm) thick in landscape orientation.
- ADA-Compliant Low Profile — Extends just 3.97" (101mm) from the wall to meet Americans with Disabilities Act clearance requirements.
- Eight-Way Tool-Less Adjustment — Positions the display flush within the kiosk window quickly and without tools.
- Thermostat-Controlled Fans — Circulation fans maintain proper airflow to keep the display and electronics at safe operating temperatures.
- Hinged Locking Frame — The top frame hinges open for easy installation and maintenance access while staying secure.
- Security Locks — Integrated locks prevent unintended access to the enclosure interior in public settings.
- Pull-Out Mount — Allows straightforward installation, adjustment, and servicing of the display.
- Pre-Assembled — Arrives assembled to streamline deployment of the full kiosk solution.
- Wide VESA Range — Supports mounting patterns from 200 x 200mm up to 600 x 400mm.
Typical Applications
- Retail and shopping environments
- Hospitality lobbies and casinos
- Entertainment venues and cinemas
- Transportation hubs and wayfinding
- Corporate and government lobbies
Technical Specifications
| Model | KIL655 |
| Display Fit | 55" displays up to 2" (50mm) thick |
| Orientation | Landscape |
| Load Capacity | 75 lb (34 kg) |
| Mounting Pattern | 200 x 200mm up to 600 x 400mm |
| Wall Profile | 3.97" (101mm), ADA compliant |
| Dimensions (W x H x D) | 56.00" x 34.10" x 3.97" (1422 x 866 x 101mm) |
| Product Weight | 75.5 lb (34 kg) |
| Finish | Gloss black powder coat |
| Package Contents | Kiosk with display mounting hardware |
| Ship Weight | 105 lb (48 kg) |
| Warranty | 5 years on metal components, 1 year on electronic components |
Frequently Asked Questions
What display size does the KIL655 fit?
It is designed for 55" displays up to 2" (50mm) thick in landscape orientation.
Is the enclosure ADA compliant?
Yes. Its 3.97" (101mm) profile meets Americans with Disabilities Act clearance requirements.
What VESA patterns are supported?
Mounting patterns range from 200 x 200mm up to 600 x 400mm.
How is the display cooled?
Thermostat-controlled circulation fans maintain airflow to keep the display and internal electronics at safe operating temperatures.
How do I access the display for service?
A hinged locking top frame and pull-out mount provide access for installation and maintenance.
Is it secure for public spaces?
Security locks prevent unintended access to the enclosure interior.
What warranty applies?
Peerless-AV provides 5 years on metal components and 1 year on electronic components.
