Panasonic PT-MZ11KLBU8 11,000 Lumens, LCD, WUXGA Resolution (1,920 x 1,200), Laser, 4K Signal Input, Information Monitor, No Lens, Black

Product Overview

The Panasonic PT-MZ11KLBU8 is a commercial 3LCD, SOLID SHINE Laser projector delivering 11,000 lm (11,800 lm center) at WUXGA (1920 x 1200) resolution. It is specified for large-venue and fixed-installation AV where sustained brightness, laser reliability, and precise image geometry matter. Integrators and AV system designers deploy it in auditoriums, houses of worship, and high-ambient commercial meeting spaces.

Product Description

The PT-MZ11KLBU8 pairs a Laser diodes light source with a 3LCD (WUXGA) imaging system for WUXGA (1920 x 1200) output rated at 11,000 lm (ISO/IEC 21118). Per Panasonic, the light source is rated at 20,000 h (NORMAL) to 50% brightness, reducing maintenance in continuous-duty installations versus lamp projectors. A dynamic contrast ratio of 3,000,000:1 (dynamic) supports deep, legible images in controlled and semi-lit rooms. Connectivity includes HDMI, DIGITAL LINK (HDBaseT), LAN for integration into managed AV systems and multi-projector setups. Lens is "l" models: no lens (optional), so throw can be matched to the venue. The projector supports 360-degree installation for ceiling, floor, and rotated mounting. For commercial deployments — large-venue projection, worship, auditoriums, rental and staging — this platform protects uptime and simplifies lifecycle planning. Plan lens selection, mounting, and signal distribution as part of the AV system design; contact Creation Networks for projector-to-lens matching and commercial deployment support.

Browse compatible Panasonic projector lenses and mounts at Creation Networks.

Key Features

• 11,000 lm (11,800 lm center) — high output for large venues and high-ambient rooms.
• Laser diodes — rated 20,000 h (NORMAL) to 50% brightness for low-maintenance continuous duty.
• WUXGA (1920 x 1200) — high-resolution imaging for detailed content.
• Contrast 3,000,000:1 (dynamic) — deep blacks and legible detail.
• Professional connectivity — HDMI, DIGITAL LINK (HDBaseT), LAN.
• 360° installation — ceiling, floor, and rotated mounting for flexible integration.

Typical Applications

• Auditorium and large-venue projection
• House of worship
• Higher-education lecture halls and training rooms
• Broadcast studio, rental and staging
• Corporate all-hands rooms and commercial meeting spaces

Technical Specifications

Frequently Asked Questions

Is a lens included?

No — this is an "l" models: no lens (optional) model; select a Panasonic lens to match your throw distance.

What is the light-source lifespan?

Panasonic rates the laser light source at 20,000 h (NORMAL) to 50% brightness, which lowers maintenance versus lamp-based projectors in continuous-duty installs.

How does it integrate into an AV system?

It provides HDMI, DIGITAL LINK (HDBaseT), LAN and 360° installation. Plan mounting, lensing, and signal distribution as part of the overall AV design; Creation Networks can assist.

Is it suitable for 24/7 or rental use?

Yes — the laser engine and filter design suit long-run installations and rental/staging. Confirm duty and environment against the datasheet.

What warranty and support apply?

Panasonic commercial warranty applies, with optional extended service plans. Contact Creation Networks for coverage and integration support.

Can Creation Networks help with lens selection and project pricing?

Yes — contact our team for projector-to-lens matching, throw-distance calculations, lead times, and project quotes.
