Panamax VT1512-IP Power Management - VT1512-IP
Product Overview
The Panamax VT1512-IP rack power management unit is a slim, vertical-format power conditioner and power sequencer built for professional AV equipment racks. It provides full-featured power conditioning — including EMI/RFI filtration, surge protection, and Automatic Voltage Monitoring (AVM) — across 12 individually controlled outlets at 15A capacity. BlueBOLT IP connectivity allows integrators and facility managers to remotely monitor, reboot, schedule, and control every outlet from any web browser or mobile app, 24/7. The VT1512-IP is the preferred AV rack power conditioner for commercial AV integrators who require remote outlet control without on-site visits.
Product Description
The VT1512-IP is a BlueBOLT-enabled vertical rack power conditioner designed specifically for AV rack installations where remote power management and energy monitoring are required. Each of its 12 outlets is individually controllable via the BlueBOLT cloud platform, enabling integrators to perform remote power cycling, set scheduled on/off commands, configure network ping-triggered reboots, and monitor energy consumption — all without dispatching a technician to the rack.
AVM (Automatic Voltage Monitoring) circuitry continuously monitors incoming line voltage. If the voltage drops below or rises above safe operating levels, the VT1512-IP automatically disconnects power to connected equipment and reconnects it once the line returns to a safe range — protecting AV components from prolonged over- and under-voltage conditions. The Protect or Disconnect surge protection circuit instantly disconnects AC power during catastrophic surge events such as lightning strikes, then automatically reconnects when line conditions normalize.
Standard EMI/RFI filtration reduces electrical noise on all 12 outlets, preventing interference from contaminating sensitive audio and video signal chains. Three outlets are spaced wide for wall-wart adapters, and six are rotated 90 degrees for improved cable management in tight rack spaces. The VT1512-IP mounts vertically to equipment rack rails using included brackets, with a 10-foot captive power cord featuring a removable NEMA 5-15P plug for length customization. For installations without cloud connectivity, an embedded local webpage provides LAN-based control, and the unit supports integration with ELAN and third-party control systems. A ground lug accommodates Panamax signal-line protection modules. The VT1512-IP is covered by a 3-year limited product warranty.
Key Features
- 12 individually BlueBOLT-controlled outlets (3 wide-spaced, 6 rotated 90°)
- 15A total current capacity (1,800W)
- Vertical rack-mount form factor with included mounting brackets
- BlueBOLT IP control: remote outlet switching, scheduling, energy monitoring, ping-reboot
- AVM (Automatic Voltage Monitoring): auto-disconnect on over/under voltage, auto-reconnect on safe return
- Protect or Disconnect surge protection: instant AC disconnect on catastrophic surge
- Standard EMI/RFI filtration on all outlets
- Power sequencing to prevent inrush and speaker thump
- Embedded local webpage for LAN control without cloud dependency
- 10-foot captive cord with removable NEMA 5-15P plug; ground lug for signal-line modules
- 3-year limited product warranty; $5,000,000 Connected Equipment Protection Policy (with signal-line modules)
Typical Applications
- Conference room AV racks requiring remote power management
- Boardroom AV systems where unattended power cycling is needed
- House of worship AV installations with distributed equipment racks
- All-hands rooms and multi-purpose event spaces
- Commercial meeting spaces managed by remote AV integrators
- Government AV installations requiring secure IP-based outlet control
Technical Specifications
| Specification | Value |
|---|---|
| AC Input | 120 VAC, 50/60 Hz |
| Total Outlets | 12 |
| Total Current Capacity | 15A (1,800W) |
| Voltage Protection Rating (UL 1449 4th Ed., 3,000A) | L-N 500V, L-G 500V, N-G 500V |
| Protection Modes | L-N, L-G, N-G |
| Initial Clamping Level | 200V Peak, 141V RMS |
| Energy Dissipation | 668 Joules |
| Peak Impulse Current | 12,000A |
| Protect or Disconnect | Yes |
| Thermal Fusing | Yes |
| BlueBOLT IP Control | Yes |
| Cord Length | 10 ft. captive with removable NEMA 5-15P |
| Dimensions | 37" L x 1.75" W x 1.75" H |
| Warranty | 3-year limited product warranty |
FAQs
Q: How many outlets does the VT1512-IP have, and are they individually controlled?
The VT1512-IP has 12 total outlets. All 12 are individually controllable via the BlueBOLT cloud platform or through the embedded local webpage, allowing selective power cycling without affecting other connected equipment.
Q: What is AVM (Automatic Voltage Monitoring) and how does it protect my equipment?
AVM continuously monitors incoming line voltage. If the voltage falls below or rises above safe operating thresholds — indicating a brownout, sag, or overvoltage condition — the VT1512-IP automatically disconnects power to all connected equipment. When the line voltage returns to a safe level, it automatically reconnects. This prevents prolonged exposure to unsafe voltages that can damage sensitive electronics.
Q: What is Protect or Disconnect, and how is it different from standard surge suppression?
Protect or Disconnect is Panamax's response to extreme surge events such as direct or nearby lightning strikes. Rather than attempting to absorb an overwhelming surge through suppression components — which can fail or degrade over time — the circuit instantly disconnects AC power to connected equipment entirely. Once the surge event clears and line conditions normalize, power reconnects automatically.
Q: Does BlueBOLT require a separate subscription or license?
BlueBOLT is Panamax's IP cloud platform for remote power management. Basic remote outlet control, scheduling, and energy monitoring are available through the BlueBOLT platform. For environments without cloud access, the VT1512-IP also provides LAN-based control through an embedded local webpage, and supports integration with ELAN and other third-party control systems. Contact Creation Networks for current BlueBOLT subscription details.
Q: Can the VT1512-IP integrate with third-party control systems?
Yes. The VT1512-IP supports LAN-based control and is compatible with ELAN and other third-party control systems for installations where direct integration into a room automation or control system is required.
Q: What is the power cord configuration, and can it be customized?
The VT1512-IP comes with a 10-foot captive power cord with a removable NEMA 5-15P plug, allowing installers to trim the cord to the required length for clean rack cable management.
Q: What warranty and equipment protection policy is included?
The VT1512-IP includes a 3-year limited product warranty. When used in conjunction with Panamax signal-line protection modules, it is also covered by a $5,000,000 Connected Equipment Protection Policy. Note that this policy applies only when purchased from an authorized Panamax internet dealer.
