Vizrt TC1SP Small Control Panel for TriCaster TC1 - FG-001589-R001

Product Overview

The Vizrt TC1SP Small Control Panel (FG-001589-R001) is a compact 14-button hardware switcher controller purpose-built for the TriCaster TC1 live production system. With 14 switcher source buttons, 11 M/E source buttons, a T-bar, and a 3-axis joystick, the TC1SP delivers the core controls broadcast operators need in a significantly smaller footprint than full-size panels. It connects via USB — no external power supply required — making it an efficient solution for tight production desks, fly-pack deployments, and space-constrained broadcast installations.

Product Description

The TC1SP is engineered for TriCaster TC1 operators who need reliable hands-on switching without the full footprint of a 2-Stripe or 4-Stripe panel. Its 14 switcher source buttons and 11 M/E source buttons are arranged in a 1.5-stripe layout, providing direct access to program and preview buses within a compact form. The T-bar enables smooth, manual transitions while the 3-axis joystick supports downstream key positioning and camera control functions. USB connectivity means the panel draws power directly from the host system — one less cable to manage in a mobile or fly-pack setup. Backlit buttons maintain visibility in dark production environments. For system integrators outfitting TriCaster TC1 installations where desk space is at a premium, or where operators prefer a compact control surface alongside a software interface, the TC1SP provides the essential tactile controls without the cost or bulk of larger panels. Compatible with TriCaster TC1 R2 and R3.

Key Features

• 14 Switcher Source Buttons — Direct one-button access to 14 sources on the program and preview buses.
• 11 M/E Source Buttons — Dedicated M/E row provides fast access to mix/effects bus sources.
• T-Bar Transition Control — Manual T-bar for smooth, precise transitions during live switching.
• 3-Axis Joystick — Supports downstream key positioning and PTZ-style camera control functions.
• USB Connectivity, No External Power — Single USB cable connects and powers the panel from the TriCaster host system.
• Compact 1.5-Stripe Layout — Smaller footprint than standard 2-stripe panels, suited for space-constrained production desks.
• Backlit Buttons — Illuminated source buttons remain visible in low-light broadcast and event environments.
• Compatible with TC1 R2 and R3 — Supports current TriCaster TC1 hardware revisions.

Typical Applications

• TriCaster TC1 installations where desk space is limited
• Fly-pack and mobile live event production
• Secondary operator positions in multi-panel production setups
• Houses of worship with compact production desk configurations
• Training and education environments with TriCaster TC1 systems

Technical Specifications

Competitor Comparison

Frequently Asked Questions

Does the TC1SP require a separate power supply?

No. The panel is bus-powered via USB and draws all required power through the USB connection to the TriCaster TC1 host system.

Is the TC1SP compatible with TriCaster models other than the TC1?

The TC1SP is specifically designed for TriCaster TC1 R2 and R3. For installations requiring compatibility with additional TriCaster models, consider the Vizrt Flex Control Panel (FG-003262).

What is the difference between the TC1SP and the 4-Stripe panel?

The TC1SP provides 14 switcher source buttons in a compact 1.5-stripe layout via USB, while the 4-Stripe panel offers four independently assignable stripes with IP connectivity for complex multi-bus and multi-engine production workflows.

Can the 3-axis joystick control PTZ cameras?

The joystick supports downstream key positioning and camera-related control functions within the TriCaster TC1 environment. Dedicated PTZ control capability depends on the TriCaster software configuration.
