Netgear M4350-24X8F8V 24-Port 10G/Multi-Gig PoE++ Fully Managed AV Switch (TAA Compliant) - XSM4340V-TAANES

Product Overview

The Netgear M4350-24X8F8V (XSM4340V-TAANES) is a Trade Agreements Act compliant fully managed AV switch built for federal and regulated multi-tier AV-over-IP deployments. This TAA compliant AV switch combines 24 Multi-Gigabit PoE++ access ports, eight 10G SFP+ ports, and eight 25G SFP28 ports in a single 1U chassis. As a GSA Schedule eligible 24-port 10G PoE++ switch, it gives integrators a federally procurable platform for Dante, NDI, and SMPTE ST 2110 video networks. It delivers the same feature set and performance as the commercial XSM4340V SKU.

Product Description

The M4350-24X8F8V is engineered for installations that mix high-power copper endpoints with fiber distribution and high-bandwidth aggregation on one device. The 24 RJ45 ports auto-negotiate across 100M/1G/2.5G/5G/10G and deliver IEEE 802.3bt PoE++ up to 90W per port for cameras, encoders, displays, and wireless access points. Eight SFP+ ports handle 10G fiber links between rooms and racks, while eight SFP28 ports provide 25G uplinks to the network core or spine. The switch ships with the Netgear AV User Interface and Engage Controller, providing one-click profiles for Dante, NDI, Q-SYS, AES67, AVB, SMPTE ST 2110, Crestron NVX, and AMX SVSI with no additional licensing. NETGEAR IGMP Plus manages Layer 2 multicast without requiring PIM, keeping dense AV-over-IP traffic contained. Virtual Chassis stacking and NSF hitless failover support high-availability designs, and the modular PSU bay accepts a second supply for redundancy.

Key Features

• TAA Compliant — Trade Agreements Act compliant and GSA Schedule eligible for federal procurement.
• 24x Multi-Gig PoE++ ports — RJ45 ports auto-negotiate 100M/1G/2.5G/5G/10G with IEEE 802.3bt PoE++ up to 90W per port.
• 8x 10G SFP+ ports — fiber distribution and inter-switch connectivity across rooms and racks.
• 8x 25G SFP28 ports — high-bandwidth aggregation toward the network core or spine.
• SMPTE ST 2110 support — suited to broadcast-grade IP video workflows.
• Netgear AV UI + Engage Controller — license-free one-click profiles for Dante, NDI, Q-SYS, AES67, AVB, ST 2110, Crestron NVX, and AMX SVSI.
• NETGEAR IGMP Plus — Layer 2 multicast management for AV-over-IP without PIM complexity.
• Virtual Chassis and NSF hitless failover — stacking and high availability for mission-critical AV networks.
• Modular PSU bay — accepts a second power supply for 1+1 redundancy.

Typical Applications

• Government meeting spaces and command facilities with multi-tier AV requirements
• Commercial meeting spaces and all-hands rooms in regulated industries
• Broadcast studios with SMPTE ST 2110 IP video
• Auditoriums and large multi-purpose rooms with dense AV-over-IP endpoints
• Higher education broadcast and media centers under federal funding

Technical Specifications

Frequently Asked Questions

Is the M4350-24X8F8V TAA compliant for federal procurement?
Yes. The XSM4340V-TAANES is the Trade Agreements Act compliant variant and is GSA Schedule eligible, delivering the same features as the commercial XSM4340V SKU.

What AV-over-IP protocols does it support?
It ships with the Netgear AV UI and Engage Controller and includes one-click profiles for Dante, NDI, Q-SYS, AES67, AVB, SMPTE ST 2110, Crestron NVX, and AMX SVSI with no additional licensing.

How much PoE does each port provide?
The 24 Multi-Gig copper ports support IEEE 802.3bt PoE++ up to 90W per port for high-power AV endpoints.

Can it be deployed for high availability?
Yes. It supports Virtual Chassis stacking, NSF hitless failover, and a modular PSU bay that accepts a second power supply for 1+1 redundancy.

What warranty and support are included?
This M4350 model is covered by the NETGEAR ProSAFE Limited Lifetime Hardware Warranty with next-business-day advance replacement. Contact our team for support details.
