Netgear XS724TM-100NAS

Product Overview

The NETGEAR XS724TM is a 24-port 10G/multi-gigabit smart-managed switch with four dedicated 10G SFP+ uplinks, the top of the S3600 series for demanding commercial AV networks. All 24 copper ports auto-negotiate 10G/5G/2.5G/1G, and four 10G SFP+ ports provide fiber aggregation to the core. Layer 2+/Lite L3 management, IPv6 support, ACLs, static routing, and optional NETGEAR Insight cloud control make it a full-featured non-PoE aggregation switch. The non-blocking 560Gbps fabric handles AV-over-IP, storage, and converged data, voice, and video at scale.

Product Description

The XS724TM is built for installations that need dense 10G connectivity, four high-bandwidth uplinks, and complete smart-switch management without PoE. Each of the 24 copper ports auto-negotiates 10G/5G/2.5G/1G, running 2.5G/5G over existing Cat5e and full 10G over Cat6A to reduce recabling. Four dedicated 10G SFP+ ports aggregate traffic to the core over fiber or copper modules, doubling the uplink capacity of comparable 16-port models. The non-blocking 560Gbps fabric forwards traffic at wire speed with a 16K MAC table, 512 VLANs, and up to 416.6 Mpps forwarding.

Management spans advanced VLANs (MAC-based, protocol-based, private), L2/L3/L4 ACLs with 802.1x authentication, IGMP/MLD snooping and querier, IPv4/IPv6 static routing, VLAN routing, DHCP server/relay/snooping, and SNMP v1/v2c/v3 with RMON. Auto-VoIP, Auto-Camera VLAN, and strict-priority/WRR queuing prioritize converged AV traffic. A Lite CLI and web GUI handle local setup, and optional NETGEAR Insight cloud management adds remote multi-site monitoring and firmware updates. Temperature- and load-based fans keep it to 29.61 dBA in a rack-mount chassis. Compare it with other S3600 models in our NETGEAR switch collection.

Key Features

• 24 10G/multi-gig ports — Every copper port auto-negotiates 10G/5G/2.5G/1G for high-bandwidth endpoints and access points.
• 4x 10G SFP+ uplinks — Four dedicated 10G fiber/copper ports aggregate heavy traffic to the network core.
• Smart Layer 2+/Lite L3 — Advanced VLANs, L2/L3/L4 ACLs, 802.1x, IGMP/MLD snooping, static routing, and DHCP services.
• Non-blocking 560Gbps fabric — Wire-speed store-and-forward switching with up to 416.6 Mpps forwarding and 512 VLANs.
• Converged AV prioritization — Auto-VoIP, Auto-Camera VLAN, and strict-priority/WRR queuing for voice, video, and data.
• NETGEAR Insight cloud — Optional remote monitoring, configuration, and firmware updates across multiple sites.
• Rack-mount design — 1U metal chassis with load-based fans rated to 29.61 dBA at full power.
• Limited Lifetime warranty — Backed by NETGEAR hardware coverage with Next Business Day replacement.

Typical Applications

• Broadcast studio AV-over-IP networks aggregating multiple 10G video sources and shared storage
• Auditorium and large all-hands room installations distributing high-bandwidth video over a 10G fabric
• Boardroom and large conference room systems needing dense 10G connectivity with four core uplinks
• Commercial meeting spaces consolidating multi-gig and 10G endpoints to a managed aggregation switch
• Government spaces requiring IPv6 management, ACL security, static routing, and multi-site oversight

Technical Specifications

Specifications sourced from the NETGEAR datasheet.

Frequently Asked Questions

How is the XS724TM different from the XS516TM?
The XS724TM has 24 copper ports and four 10G SFP+ uplinks with a 560Gbps fabric, versus 16 ports and two SFP+ uplinks on the XS516TM. It suits larger deployments needing more ports and uplink capacity.

Does it provide PoE?
No. The XS724TM is a non-PoE 10G/multi-gig aggregation switch. Pair it with a PoE switch like the MS-series for powered devices.

What speeds do the copper ports support?
Every copper port auto-negotiates 10G/5G/2.5G/1G, running 2.5G/5G over existing Cat5e and full 10G over Cat6A.

Can it prioritize AV-over-IP and voice traffic?
Yes. Advanced VLANs, IGMP/MLD snooping and querier, Auto-VoIP, Auto-Camera VLAN, and strict-priority/WRR queuing keep multicast video, voice, and data segmented and prioritized.

Can I manage it remotely across multiple sites?
Yes. Optional NETGEAR Insight cloud management provides remote configuration, monitoring, and firmware updates with a single pane-of-glass multi-site view.

What warranty and support are included?
The XS724TM carries a NETGEAR Limited Lifetime hardware warranty with Next Business Day replacement, a 1-year Insight subscription, and optional ProSUPPORT service packs.
