Netgear XS505M-100NAS
Product Overview
The NETGEAR XS505M is a 5-port 10G/multi-gig unmanaged switch with four 10G copper ports and one 10G SFP+ fiber uplink, built for plug-and-play high-speed AV connectivity. Each copper port auto-detects 100M/1G/2.5G/5G/10G and delivers the exact speed each device needs over existing cabling, with no configuration required. The SFP+ port provides a 1G/10G fiber uplink to your core or aggregation switch. With a 100Gbps line-rate fabric and a durable metal case, it is a compact way to add 10G to NAS, workstations, and AV-over-IP gear.
Product Description
The XS505M brings 10G connectivity to small AV and editing setups without management overhead. Its four copper ports use 5-speed technology to auto-negotiate 100M/1G/2.5G/5G/10G, giving each connected device its full speed rather than downgrading sub-10G devices to 1G as standard 10G switches do. The ports accept regular Cat5e for 2.5G/5G and Cat6A for full 10G, reducing recabling costs. A single 10G SFP+ port adds a fiber or copper-module uplink to the network core or to a 10G-capable aggregation switch.
The 100Gbps line-rate fabric forwards traffic at wire speed with low latency, jumbo frame support up to 9K, and 802.1p QoS and DSCP honoring for prioritized traffic. There is nothing to configure: connect devices and the switch handles speed negotiation automatically. The metal case mounts on a 19-inch rack or sits on a desktop, and an active fan keeps it whisper-quiet. It is well suited to connecting a 10G NAS, multi-gig workstations, and high-bandwidth AV endpoints in a small studio or editing suite. Browse comparable 10G models in our NETGEAR switch collection.
Key Features
- 5-speed 10G copper ports — Four ports auto-negotiate 100M/1G/2.5G/5G/10G, delivering each device its full speed with no downgrade.
- 10G SFP+ uplink — One dedicated 1G/10G SFP+ port for a fiber or copper-module uplink to the core.
- 100Gbps line-rate fabric — Wire-speed, store-and-forward switching across all ports with low latency.
- Plug-and-play — No software or configuration; connect devices and speeds negotiate automatically.
- Existing-cable friendly — Runs 2.5G/5G over Cat5e and full 10G over Cat6A to reduce recabling.
- QoS support — 802.1p CoS and DSCP honoring prioritize AV and voice traffic.
- Durable metal case — 19-inch rack-mount or desktop deployment with a whisper-quiet active fan.
- ProSAFE Limited Lifetime warranty — Backed by lifetime hardware coverage and 24/7 technical support.
Typical Applications
- Broadcast studio and editing suite connections to a 10G NAS and multi-gig workstations
- Conference room AV systems needing a 10G uplink for high-bandwidth video sources
- Huddle room and small meeting space deployments adding 10G to existing cabling
- Commercial meeting spaces aggregating multi-gig endpoints to a 10G fiber backbone
- Multi-purpose rooms requiring fast plug-and-play connectivity without a managed switch
Technical Specifications
| Ports | 4 x 10G/multi-gig RJ-45 (100M/1G/2.5G/5G/10G) |
| Uplink | 1 x 10G SFP+ (1G/10G) |
| Switching Bandwidth | 100Gbps (line-rate) |
| Packet Forwarding Rate | 14,880,952 fps at 10G (64-byte) |
| MAC Address Table | 2K (dynamic) |
| Packet Buffer | 128KB |
| Jumbo Frames | Up to 9K |
| Acoustic Noise | 22.5 dBA @ 25°C |
| Dimensions (W x D x H) | 328 x 169 x 43.2 mm (12.91 x 6.65 x 1.7 in) |
| Mounting | Desktop, rack-mount |
| Warranty | ProSAFE Limited Lifetime, NBD Replacement |
Specifications sourced from the NETGEAR datasheet.
Frequently Asked Questions
Why choose the XS505M over a standard 10G switch?
Its 5-speed ports deliver each device its exact speed (100M/1G/2.5G/5G/10G) instead of downgrading sub-10G devices to 1G, which preserves multi-gig performance for access points and 2.5G/5G gear.
Do I need Cat6A cabling?
For full 10G, Cat6A is recommended (or Cat6 under 55 m / Cat5e under 45 m). For 2.5G and 5G, existing Cat5e works fine.
What is the SFP+ port used for?
The 10G SFP+ port accepts fiber or copper modules for a 1G/10G uplink to your core or aggregation switch, keeping the four copper ports free for endpoints.
Is it managed?
No. The XS505M is unmanaged and plug-and-play, so there is no configuration. It does honor 802.1p and DSCP QoS tags for prioritized traffic.
Is it quiet enough for a studio or office?
It uses a whisper-quiet active fan rated at 22.5 dBA, low enough for editing suites and quiet rooms.
What warranty and support are included?
The XS505M carries a NETGEAR ProSAFE Limited Lifetime warranty with lifetime 24/7 online technical support and Next Business Day replacement.
