Netgear MS108TUP-100NAS

Product Overview

The NETGEAR MS108TUP is an 8-port multi-gigabit Ultra60 PoE++ smart switch with Insight cloud management for commercial AV networks. All eight ports run 1G/2.5G, with four Ultra60 PoE++ ports at up to 60W and four PoE+ ports at up to 30W, drawing from a 230W total PoE budget. Layer 2+/Lite L3 features, IPv6 management, ACLs, and remote NETGEAR Insight cloud control make it a manageable edge switch that stays fanless and silent. It powers and manages WiFi 6 access points, IP cameras, and VoIP endpoints from a single compact unit.

Product Description

The MS108TUP gives AV integrators full smart-switch control in a fanless desktop form factor. Each of the eight 2.5GBASE-T copper ports auto-negotiates 100M/1G/2.5G over existing Cat5e cabling, so multi-gig WiFi 6 access points and 2.5G cameras connect without recabling. Ports 1-4 deliver Ultra60 PoE++ (802.3bt) up to 60W per port and ports 5-8 deliver PoE+ (802.3at) up to 30W, all within a 230W budget. Uninterrupted PoE keeps powered devices online through firmware upgrades and soft reboots, and PoE self-healing reboots a connected device automatically if it stops responding.

Beyond power, the MS108TUP adds Layer 2+/Lite L3 management: VLANs, L2/L3/L4 ACLs with 802.1x port authentication, IGMP snooping and querier, IPv6 QoS and ACLs, and SNMP v1/v2c/v3 with RMON monitoring. The non-blocking 40Gbps fabric forwards traffic at wire speed, and a Lite CLI plus the web GUI cover local configuration. Optional NETGEAR Insight remote cloud management lets you monitor, configure, schedule PoE, and update firmware from a mobile app or web portal across multiple sites. See how it compares to other models in our NETGEAR switch collection.

Key Features

• Ultra60 PoE++ power — Four ports deliver up to 60W (802.3bt) and four deliver up to 30W (802.3at) from a 230W budget for APs, cameras, and phones.
• Multi-gig 2.5G ports — All eight RJ-45 ports auto-negotiate 100M/1G/2.5G over Cat5e for WiFi 6 access points and 2.5G endpoints.
• Smart Layer 2+/Lite L3 — VLANs, L2/L3/L4 ACLs, 802.1x, IGMP snooping/querier, and IPv6 management for granular control.
• NETGEAR Insight cloud — Optional remote monitoring, configuration, PoE scheduling, and firmware updates from a mobile app or web portal.
• Uninterrupted PoE and self-healing — Power stays on during upgrades and unresponsive devices reboot automatically.
• Non-blocking 40Gbps fabric — Store-and-forward switching at wire speed across all ports.
• Fanless silent operation — Zero acoustic noise suits quiet rooms and AV equipment closets.
• Limited Lifetime warranty — Backed by NETGEAR hardware coverage and optional support tiers.

Typical Applications

• Conference room AV systems requiring managed VLANs for video, voice, and data on one switch
• Huddle room and meeting space WiFi 6 access-point and camera deployments with remote cloud management
• Training room installations needing PoE++ for cameras and access points plus 802.1x security
• House of worship audio and IP-camera networks segmented with ACLs and Insight monitoring
• Government spaces requiring IPv6 management and centralized multi-site oversight

Technical Specifications

Specifications sourced from the NETGEAR datasheet.

Frequently Asked Questions

What is the difference between the MS108TUP and the unmanaged or Plus models?
The MS108TUP is a full smart switch. It adds L2/L3/L4 ACLs, 802.1x, IPv6 management, SNMP monitoring, a Lite CLI, and optional NETGEAR Insight cloud management on top of the same multi-gig PoE++ hardware.

Can I manage the switch remotely across multiple sites?
Yes. Optional NETGEAR Insight remote cloud management lets you monitor, configure, schedule PoE, and push firmware from a mobile app or web portal with a single pane-of-glass multi-site view.

Does it support 2.5G over existing cabling?
Yes. All eight ports auto-negotiate 100M/1G/2.5G over Cat5e, so multi-gig access points and cameras connect without recabling.

How does uninterrupted PoE help AV deployments?
Uninterrupted PoE keeps cameras, phones, and access points powered through firmware upgrades and soft reboots, and PoE self-healing reboots an unresponsive device automatically.

Is it suitable for AV-over-IP traffic?
Yes. VLANs, IGMP snooping and querier, and QoS keep multicast AV streams, voice, and data properly separated and prioritized.

What warranty and support come with it?
The MS108TUP includes a NETGEAR Limited Lifetime hardware warranty plus a 1-year Insight subscription, with optional Sprint and Overdrive support tiers.
