Netgear M4350-24M4X4V 24-Port 2.5G PoE++ Fully Managed AV Switch (TAA Compliant) - MSM4332-TAANES

Product Overview

The NETGEAR M4350-24M4X4V (MSM4332-TAANES) is a TAA-compliant fully managed AV switch built for federal and public sector networks moving to 2.5G AV-over-IP infrastructure. It combines 24 2.5G PoE++ access ports, four 10G/Multi-Gig PoE++ ports, and four 25G SFP28 uplinks in a Trade Agreements Act compliant chassis. As a 2.5G PoE++ AV switch with native SMPTE ST 2110, Dante, NDI, and Q-SYS support, it suits integrators specifying TAA-compliant infrastructure for high-density AV endpoints. The MSM4332-TAANES delivers the same feature set as the commercial SKU in a procurement-ready package.

Product Description

The M4350-24M4X4V ships with NETGEAR AV OS and the Engage Controller, providing one-click configuration profiles for Dante, NDI, Q-SYS, AES67, AVB, SMPTE ST 2110, Crestron NVX, and AMX SVSI with no per-protocol licensing. It functions as a SMPTE ST 2110 Grand Master Clock and Boundary Clock for AES67 and ST2059-2 applications, which supports precise timing across broadcast and pro AV endpoints. NETGEAR IGMP Plus delivers Layer-2 multicast functionality out of the box for AV-over-IP traffic without PIM, and Auto-Trunk and Auto-LAG simplify multi-switch deployments with other M4350 and M4250 switches. The 24 2.5G access ports and four 10G/Multi-Gig ports all deliver IEEE 802.3bt PoE++, with an 800W internal PSU providing a 522W base PoE budget that scales to 2,520W using modular power supplies. Two PSU slots support 1+1 redundancy or EPS power sharing with APS600Wv3, APS1200Wv2, or APS2000Wv2 supplies. A full Layer 3 feature set covers static, policy-based, and dynamic routing, while Virtual Chassis stacking provides NSF Non-Stop Forwarding and hitless failover. Quiet Mode operation at 34.8 dB keeps it appropriate for occupied AV spaces.

Key Features

• TAA compliant — Meets Trade Agreements Act requirements for federal, GSA, and public sector procurement.
• 24x 2.5G PoE++ ports — IEEE 802.3bt 2.5GBASE-T for high-density AV and wireless endpoints.
• 4x 10G/Multi-Gig PoE++ ports — IEEE 802.3bt for higher-bandwidth powered devices.
• 4x 25G SFP28 uplinks — High-bandwidth aggregation to core or spine switches.
• SMPTE ST 2110 timing — Grand Master Clock and Boundary Clock for AES67 and ST2059-2 applications.
• NETGEAR AV OS + Engage Controller — One-click profiles for Dante, NDI, Q-SYS, AES67, AVB, ST 2110, Crestron NVX, and AMX SVSI, no license required.
• NETGEAR IGMP Plus — Layer-2 multicast optimization for AV-over-IP without PIM configuration.
• Scalable PoE budget — 522W base from the 800W internal PSU, expandable to 2,520W with modular supplies.
• Power redundancy — Two PSU slots for 1+1 redundancy or EPS sharing (APS600Wv3 / APS1200Wv2 / APS2000Wv2).
• Virtual Chassis with NSF — Stacking with Non-Stop Forwarding and hitless failover plus Auto-Trunk and Auto-LAG.
• Jumbo frame support — Up to 12KB frames for high-throughput AV and data flows.
• Quiet operation — Quiet Mode at 34.8 dB for occupied rooms and AV racks.

Typical Applications

• Government meeting spaces — TAA-compliant 2.5G AV infrastructure for agency conference and briefing rooms.
• Broadcast studio — SMPTE ST 2110 timing and 25G uplinks for IP-based video production.
• Commercial meeting spaces — High-density 2.5G AV endpoints in regulated-industry facilities requiring TAA documentation.
• House of worship — TAA-compliant Dante and NDI distribution over a managed multicast network.
• Training rooms — Multi-purpose AV-over-IP rooms aggregating cameras and encoders to 25G uplinks.
• Auditorium — High-bandwidth AV-over-IP with PoE++ for displays, encoders, and decoders.

Technical Specifications

Frequently Asked Questions

Does the M4350-24M4X4V meet federal TAA procurement requirements?
Yes. The MSM4332-TAANES is the TAA-compliant variant built to satisfy Trade Agreements Act requirements for GSA Schedule and federal procurement, with the same feature set as the commercial SKU.

What makes this switch suited to SMPTE ST 2110 broadcast workflows?
It operates as a Grand Master Clock and Boundary Clock for AES67 and ST2059-2 applications and includes Engage Controller profiles for ST 2110, providing the precise timing IP video production requires.

How much PoE power is available?
The 800W internal PSU provides a 522W base PoE++ budget across 28 PoE++ ports, expandable to 2,520W using modular APS600Wv3, APS1200Wv2, or APS2000Wv2 supplies in the two PSU slots.

Can I stack it with other M4350 or M4250 switches?
Yes. Virtual Chassis stacking with NSF provides hitless failover, and Auto-Trunk and Auto-LAG auto-connect with other M4350 and M4250 switches to simplify multi-switch AV deployments.

What warranty and support are available?
This model is backed by the NETGEAR ProSAFE Limited Lifetime Hardware Warranty. NETGEAR also offers Sprint (24/5) and Overdrive (24/7, 2h SLA, NBD RMA) support contracts. Contact our team for help selecting coverage.
