Netgear GSM4210PX-100NAS M4250-8G2XF-POE+ FULLY MANAGED DESKTOP SWITCH

Product Overview

The NETGEAR GSM4210PX-100NAS (M4250-8G2XF-PoE+) is a compact, fanless AV Line desktop managed switch built for AV-over-IP. It pairs eight 1G PoE+ copper ports with a 220W power budget and two 1G/10G SFP+ fiber uplinks, giving edge AV devices high-bandwidth uplinks from a switch small enough for a conference room, mobile studio, or under a desk. Pre-configured audio and video profiles, a dedicated AV web GUI, and NETGEAR IGMP Plus make this fully managed AV switch fast to deploy.

Product Description

This fanless desktop switch provides eight 1G PoE+ (802.3af/at) RJ45 ports with a 220W total PoE budget and two 1G/10G SFP+ fiber ports for high-bandwidth uplinks to the core. The dedicated AV web GUI uses color-coded, port-based AV profiles so integrators can deploy networked audio, video, and control signals without command-line setup. Audio profiles include Dante, Q-SYS, AES67, and AVB (AVB license sold separately); video profiles include AMX SVSI, Crestron NVX, Q-SYS, NDI, and Dante, along with mixed audio/video/control profiles. NETGEAR IGMP Plus, Auto-Trunk, and Auto-LAG enable plug-and-play multicast and multi-switch interconnect. A full Layer 2/Layer 3 engine supports static, RIP, and PIM routing, a DHCP server, and PTPv2. The switch shares a consistent switching engine and management model across the M4250, M4300, and M4500 families and is managed through the AV GUI, IT GUI, CLI, SNMP, sFlow, RSPAN, and NETGEAR NMS300. Its silent, fanless form factor suits installation outside the AV rack.

Key Features

• 8x 1G PoE+ ports (220W) — Power displays, cameras, access points, and AV endpoints.
• 2x 1G/10G SFP+ uplinks — High-bandwidth fiber uplinks from the edge to the core.
• Dedicated AV web GUI — Color-coded, port-based AV profiles for fast, error-free setup.
• NETGEAR IGMP Plus — Layer 2 multicast for AV-over-IP without PIM complexity.
• Audio profiles — Dante, Q-SYS, AES67, and AVB (AVB license sold separately).
• Video profiles — AMX SVSI, Crestron NVX, Q-SYS, NDI, and Dante, plus mixed profiles.
• Auto-Trunk and Auto-LAG — Plug-and-play interconnect between switches.
• Full Layer 2/Layer 3 engine — Static, RIP, and PIM routing plus a DHCP server.
• PTPv2 support — Precision clock synchronization for time-sensitive AV.
• Fanless desktop design — Silent operation for rooms outside the AV rack.

Typical Applications

• Conference room — Silent edge switching with 10G uplinks to the core.
• Huddle room — Compact PoE+ switching for cameras, displays, and endpoints.
• Broadcast studio — Portable AV-over-IP switching for mobile production and flypacks.
• Training room — Distribute NDI, AMX SVSI, and Crestron NVX video workflows.
• House of worship — Networked Dante, Q-SYS, and AES67 audio for installed sound.

Technical Specifications

Frequently Asked Questions

How much PoE power does the GSM4210PX provide?
It delivers 802.3af/at PoE+ across eight ports with a 220W total power budget shared among connected devices.

Can it provide 10G uplinks?
Yes. The two SFP+ ports support 1G or 10G fiber uplinks for high-bandwidth connections to the network core.

Which AV-over-IP platforms are supported?
It ships with profiles for Dante, Q-SYS, AES67, and AVB audio, and Crestron NVX, AMX SVSI, Q-SYS, NDI, and Dante video. AVB requires a separate license.

Is it quiet enough for a conference room?
Yes. The fanless desktop design operates silently, making it suitable for rooms and spaces outside the AV rack.

What warranty is included?
It is backed by NETGEAR's ProSAFE limited lifetime hardware warranty.
