Middle Atlantic UCP-SF 2SP HINGED UCP FRAME KIT
Product Overview
The Middle Atlantic UCP-SF is a 2-space hinged UCP (Universal Connector Panel) frame kit that provides rear access to installed modules via a hinged door secured by captive 10-32 thumbscrews. The kit holds 5 UCP modules in the front face panel and occupies 2 rack spaces (3.5 inches). It includes a pair of threaded FK bars, a hinged ear, a captive thumbscrew ear, and all module mounting hardware.
Product Description
The UCP-SF Hinged UCP Frame Kit from Middle Atlantic Products is the hinged version of the FK2 frame kit, providing the same 5-module UCP front panel capacity with the added capability of swinging the frame open for rear access to module wiring and connections. The UCP (Universal Connector Panel) system allows integrators to create custom connector panels by selecting individual module inserts for audio, video, data, and power connections, then mounting them in a frame kit that provides the rack-mount housing. The hinged design of the UCP-SF makes it appropriate for installations where periodic access to the rear of the connector modules is required, such as when terminations need to be changed or added. Captive 10-32 thumbscrews hold the frame closed securely and allow tool-free opening without risk of losing fasteners. The kit includes all hardware needed for complete assembly, including the FK bar pair, hinged ear, captive thumbscrew ear, and module mounting hardware. The 2-space form factor occupies 3.5 inches of rack height, which matches the standard 2U rack space dimension.
Key Features
- 2U / 2SP Hinged Frame — 2-space frame kit with hinged door for rear module access.
- 5 UCP Module Capacity — Front face holds 5 Universal Connector Panel modules.
- Tool-Free Opening — Captive 10-32 thumbscrews allow opening without tools.
- Complete Kit — Includes FK bars, hinged ear, thumbscrew ear, and module mounting hardware.
- Rear Access — Hinged design provides access to module wiring and terminations.
Technical Specifications
| Specification | Value |
|---|---|
| Model | UCP-SF |
| Rack Spaces | 2U (2SP) / 3.5 inches |
| Module Capacity | 5 UCP modules |
| Access | Hinged with captive thumbscrews |
| Fasteners | Captive 10-32 thumbscrews (tool-free) |
| Contents | FK bar pair, hinged ear, thumbscrew ear, module hardware |
| Brand | Middle Atlantic Products |
