Middle Atlantic SNE24F-2436 – SNE24 Open Frame 24U 36"D

Product Overview

The Middle Atlantic SNE24F-2436 is a 24U open-frame two-post rack with 10-32 rails and a 36-inch depth, designed for AV and IT environments where all-angle equipment access and unrestricted airflow are required, and where the 42-inch depth of the SNE24F-2442 exceeds the installation's space or equipment requirements. As part of the SNE24 series, this open frame provides a compact 24U height with a 36-inch depth that balances rear cable management clearance with a reduced overall footprint. AV integrators and IT managers seeking a 24U open frame rack 36-inch depth, an SNE24 two-post rack with 10-32 rails, or a Middle Atlantic open frame rack shallow depth will find this model appropriate for data closets and equipment rooms with moderate equipment depth profiles.

Product Description

The SNE24F-2436 provides 24 rack spaces on a two-post open frame with 10-32 tapped rails, eliminating the airflow restrictions of enclosed cabinets and providing complete front, rear, and side access to installed equipment. The 36-inch depth accommodates most standard AV and IT rack-mount equipment, including moderate-depth servers, patch panels, AV distribution gear, and network switches, while providing enough rear clearance for structured cable dressing. Compared to the 42-inch variant, the 36-inch depth reduces the cabinet's overall floor footprint, which matters in equipment rooms with depth constraints. Open frame construction simplifies cable routing because cables can enter and exit at any angle without routing through panels or doors. The 10-32 rail standard ensures compatibility with standard rack hardware and Middle Atlantic accessories including cable management, power distribution, and shelving. The SNE24F-2436 is also compatible with SNE24 fan door assemblies for adding active cooling when the open frame is enclosed with optional door kits. Available through Creation Networks, an authorized Middle Atlantic distributor.

Key Features

• 24U Rack Height — Compact format for smaller equipment rooms, closets, and staging environments.
• 36-Inch Depth — Handles standard rack-mount equipment depth with rear cable clearance and reduced footprint.
• Open Frame Two-Post Design — Unrestricted airflow and all-angle equipment access.
• 10-32 Tapped Rails — Compatible with standard rack hardware and Middle Atlantic accessories.
• Simplified Cable Routing — Cables enter and exit from any angle without routing through door panels.
• Fan Door Compatible — Accepts SNE24 fan door assemblies for active cooling if enclosed.

Typical Applications

• Small data closets and equipment alcoves requiring open-air cooling
• IT patching and distribution rack deployments with frequent cable changes
• AV distribution and signal processing equipment in constrained spaces
• Server and network gear in environments with ambient temperature control
• Lab and staging environments where frequent equipment changes occur

Technical Specifications

Frequently Asked Questions

When should I choose the 36-inch depth over the 42-inch SNE24F-2442?

Choose the 36-inch model when your equipment chassis depths do not exceed 30 inches and floor depth is limited. The 42-inch variant provides more rear cable dressing room. Both are available at creationnetworks.net.

Can I add fan doors or side panels to the SNE24F-2436?

Yes. The SNE24 series accepts optional fan door assemblies and side panels. See SNE24 accessories at creationnetworks.net.

What rail thread does the SNE24F-2436 use?

The SNE24F-2436 uses 10-32 tapped rails, the standard thread pattern for professional AV and IT rack hardware.
