Middle Atlantic MPR Power Module 30A, L5-30R Twistlock - RLM30-L530-1
Product Overview
The Middle Atlantic RLM30-L530-1 is an MPR (Multi-Purpose Raceway) power module rated at 30 amps, featuring an L5-30R twistlock outlet. Engineered for high-current AV and IT rack power applications, this raceway module delivers a single 30A circuit with a locking connector that prevents accidental disconnection in critical infrastructure environments. Available at creationnetworks.net.
Product Description
The RLM30-L530-1 installs into Middle Atlantic MPR Multi-Purpose Raceway enclosures and provides a dedicated 30-amp NEMA L5-30R twistlock outlet for high-draw equipment including large UPS units, power amplifiers, and server infrastructure requiring a dedicated 30A locking circuit. The twistlock mechanism ensures power connections remain secure in rack environments subject to vibration or movement. IT managers and AV integrators deploy this module when equipment power requirements exceed standard 15A or 20A circuit capacity.
Key Features
- 30-amp capacity for high-draw AV and IT equipment
- NEMA L5-30R twistlock outlet prevents accidental disconnection
- Installs into Middle Atlantic MPR Multi-Purpose Raceway systems
- Single outlet module for dedicated circuit isolation
- Locking connector compatible with L5-30P twistlock plugs
- Supports 125V AC circuits at 30A continuous load
Typical Applications
- High-draw AV power amplifier dedicated circuit connections
- Large UPS and power conditioning equipment in rack environments
- Server and network infrastructure requiring 30A locking power feeds
- Broadcast and production racks with high-current draw equipment
- Data center ancillary equipment with 30A power requirements
Technical Specifications
| Specification | Value |
|---|---|
| Model | RLM30-L530-1 |
| Amperage | 30A |
| Outlet Type | NEMA L5-30R Twistlock |
| Voltage | 125V AC |
| Module Count | 1 outlet |
| Series | MPR Multi-Purpose Raceway |
| Vendor | Middle Atlantic |
FAQ
- What plug type mates with the L5-30R outlet?
- The NEMA L5-30P twistlock plug mates with the L5-30R outlet on this module. Rotate the plug clockwise to lock.
- Can I install multiple RLM30-L530-1 modules in one MPR raceway?
- Module count is limited by available MPR raceway space and the amperage capacity of the branch circuit feeding the raceway. Consult Middle Atlantic MPR configuration guidelines.
- Is this module suitable for 208V or 240V applications?
- No. The L5-30R is rated for 125V AC. For 208V or 240V applications, select the appropriate L6 or L14 series outlet module.
- Where can I order this module?
- Visit creationnetworks.net for pricing, availability, and MPR configuration assistance.
