Middle Atlantic MPR Module 20A, Controlled Stand-Alone - RLM-20-1CA
Overview
The Middle Atlantic RLM-20-1CA is a 20A controlled standalone power module for MPR Series vertical raceways. It provides remote and local outlet control with LED and contact closure status indication, allowing integrators to manage power distribution to connected equipment without requiring a dedicated rack PDU.
Description
The RLM-20-1CA ships pre-installed in an MPR-style enclosure with an attached 9-foot 12-3 AWG power cord, making it immediately deployable without additional assembly. The module provides two NEMA 5-20R outlets on a single 20A circuit controlled by both remote and local switching. LED indicators and dry contact closure output allow integration with control systems for automated power sequencing or status monitoring. Its standalone form factor gives integrators a fast, flexible solution for power control in a variety of installation scenarios beyond traditional MPR raceway configurations.
Key Features
- 20A standalone controlled power module
- 2 x NEMA 5-20R outlets on 1 controlled circuit
- Remote and local control capability
- LED and contact closure status indication
- Pre-installed in MPR-style enclosure with 9-foot cord attached
- Ready to use out of the box — no assembly required
- Certifications: RoHS, GREENGUARD
Technical Specifications
| Attribute | Value |
|---|---|
| Model | RLM-20-1CA |
| Amperage | 20A |
| Circuits | 1 |
| Outlets | 2 x NEMA 5-20R |
| Plug | NEMA 5-20P |
| Cord Gauge | 12-3 AWG |
| Cord Length | 9.0 ft / 2.7 m |
| Control | Remote and local |
| Status Indication | LED and contact closure |
| Dimensions (D x H x W) | 8.5 x 3.8 x 4.0 in / 21.6 x 9.7 x 10.2 cm |
| Certifications | RoHS, GREENGUARD |
