Middle Atlantic LH-BCN Narrow Bridging Cabinet with Vertical Rackmount for Console Ganging

Product Overview

The Middle Atlantic LH-BCN Narrow Bridging Cabinet with Vertical Rackmount is a purpose-built console integration unit designed to connect adjacent console sections while providing vertical rack space for equipment that must be centrally located in a console run. It fills the structural and aesthetic gap between console sections and adds usable vertical racking within the bridge span.

Product Description

In broadcast, control room, and large conference room console configurations, individual console sections are often arranged side by side in a curved or straight run. The LH-BCN bridges the gap between two sections in a narrow footprint—maintaining the visual and structural continuity of the console—while providing a vertically oriented rack bay for monitors, small displays, or rack-mount equipment that benefits from central positioning in the operator's field of view. The unit integrates directly with Middle Atlantic's LH (Legrand Hub) console system and is finished to match adjacent console sections.

Key Features

• Narrow form factor—bridges adjacent console sections without consuming excessive operator workspace
• Integrated vertical rackmount bay for monitors, displays, or rack equipment
• Designed for integration with Middle Atlantic LH console series
• Structural bridging eliminates console section gaps in multi-section runs
• Finished to match adjacent LH console sections

Typical Applications

• Broadcast control rooms with multi-section console runs
• Video production and post-production control surfaces requiring centrally mounted displays
• Large conference room and command center consoles spanning multiple operator positions
• NOC and operations center consoles with vertically mounted equipment

Technical Specifications

Frequently Asked Questions

What is the difference between the LH-BCN and a standard LH console section?

Standard LH console sections are full operator positions. The LH-BCN is a narrow bridge unit—it does not provide a full operator workspace but instead connects two standard sections and adds a vertical rack bay within the bridge gap. It is used where a full section would be too wide but a structural and aesthetic connection is still required.

Can the LH-BCN be used at the end of a console run?

The LH-BCN is designed as a bridging unit between two sections. For end-of-run applications, different LH end panel or cap accessories should be specified. Contact Creation Networks for the correct end treatment.

What equipment can be mounted in the vertical rack bay?

The vertical rack bay accommodates rack-mount equipment oriented vertically—such as small monitors, touch panels, or signal processing units. Consult the Middle Atlantic LH-BCN dimensional drawing for rackmount dimensions. Contact Creation Networks for documentation.
