Middle Atlantic CAP5 – 5-Space Clamping Rackshelf

Product Overview

The Middle Atlantic CAP5 is a 5-space clamping rackshelf engineered to hold non-rackmount AV components securely inside any standard 19-inch equipment rack. Rubber-lined clamps grip gear from the top, while adjustable rear L brackets keep units from shifting backward. Built from 16-gauge steel with a vented bottom, the CAP5 is a dependable mounting solution for fixed installations and mobile rack applications alike.

Product Description

Half-rack and consumer-grade components rarely come with rack ears, and loose gear inside a rack invites cable strain and damage in transit. The CAP5 clamping rackshelf solves this with a captive mounting approach: set the component on the shelf, tighten the rubber-lined clamps from above, and position the adjustable rear L brackets so the unit cannot be pushed back. The result is a component shelf that holds streaming boxes, modulators, small amplifiers, and signal processors firmly in place. The vented bottom promotes passive airflow around heat-producing electronics, helping equipment stay within operating temperature in enclosed racks. Occupying five rack spaces, the CAP5 provides a useable shelf area of 17.38 inches wide by 15.10 inches deep, giving taller components the clearance they need. The 16-gauge steel construction maintains structural integrity in mobile and road-case applications where vibration is a constant concern. A durable black powder coat finish matches Middle Atlantic racks and resists scratches over years of service. The shelf ships ready-to-assemble to reduce packaging volume and shipping cost. For shallower gear, the same clamping design is available in other CAP Series heights to match your rack elevation plan.

Key Features

• Rubber-Lined Clamps — Secure components from the top without marring the chassis finish.
• Adjustable Rear L Brackets — Prevent mounted units from being pushed backward in the rack.
• 5-Space Height — Accommodates taller non-rackmount AV components in a standard 19-inch rack.
• Vented Bottom — Supports passive cooling and efficient airflow around heat-generating gear.
• 16-Gauge Steel Construction — Maintains structural integrity in mobile and high-vibration applications.
• Black Powder Coat Finish — Durable finish that matches standard equipment rack hardware.
• Ready-to-Assemble Design — Ships flat to save space and reduce freight cost.
