Midas DM12 12-Input Analog Live and Studio Mixer

Product Overview

The Midas DM12 analog mixer is a 12-input analog mixing console for live sound and studio recording, featuring 8 MIDAS microphone preamplifiers, a 3-band channel EQ with sweepable mid frequency, and 2 switchable pre/post-fader aux sends per channel. As the smaller sibling of the DM16, the DM12 shares the same British-voiced EQ character and Midas preamp quality in a more compact form factor suited to smaller input counts. It is the entry-level option in the Midas analog console range and is a practical choice for small rehearsal spaces, conference room audio, utility sub-mixing, and any application where a straightforward analog signal path is preferred over digital.

Product Description

The Midas DM12 live studio mixer provides 8 mono channels and 2 stereo channels, with each mono channel offering a balanced XLR microphone input, a balanced 1/4-inch TRS line input, a 1/4-inch TRS insert point, and full 3-band EQ. The 8 MIDAS mic preamps deliver the same transparent, low-noise gain structure found in Midas’ larger consoles, with a mic gain range of 10 to 60 dB and switchable +48V phantom power applied globally. The 3-band EQ on each mono channel provides shelving high at 12 kHz, shelving low at 80 Hz, and a sweepable mid band covering 150 Hz to 3.5 kHz with up to 15 dB of boost or cut per band — the same British EQ voicing that characterizes the DM16.

The two stereo line channels (9/10 and 11/12) accept balanced TRS inputs and include a stereo gain control and balance control on each pair, accommodating keyboards, stereo playback sources, or effects returns. Aux sends 1 and 2 are available on every channel with pre/post-fader switching, enabling two independent monitor or effects sends simultaneously. The master section provides 2 balanced TRS aux outputs, 2 balanced TRS monitor outputs, 2 balanced XLR main outputs with 60 mm master faders, 1/4-inch TRS main bus inserts, 2-track RCA I/O for recording or playback connection, and a stereo 1/4-inch TRS headphone output. The internal switch-mode power supply accepts 100–240VAC, so no external transformer is required for international use.

As a compact analog mixer, the DM12 measures 95 mm H x 328 mm W x 370 mm D and weighs 3.9 kg — lighter and narrower than the DM16, making it easy to transport to rehearsals or set on a small utility shelf. There is no digital connectivity, network interface, or remote control; every adjustment is made directly at the panel. For users who need more than 8 mic inputs, the DM16 adds 4 additional MIDAS preamps and 4 more mono channels in the same product family.

Key Features

• 8 MIDAS Microphone Preamplifiers — Transparent, low-noise preamp design with switchable +48V phantom power and 10–60 dB mic gain range.
• 12 Total Inputs — 8 mono channels (XLR mic + 1/4-inch TRS line + insert) and 2 stereo line channels (1/4-inch TRS) covering standard small-format input requirements.
• 3-Band EQ with Sweepable Mid — British-voiced shelving high (12 kHz) and low (80 Hz) plus sweepable mid from 150 Hz to 3.5 kHz; up to 15 dB boost/cut per band on mono channels.
• 2 Switchable Aux Sends — Pre/post-fader switchable per channel for independent monitor mixes, effects routing, or a combination of both.
• Channel Insert Points — 1/4-inch TRS insert on each mono channel for inline patching of outboard dynamics or EQ.
• Balanced XLR Main Outputs — Two XLR main outputs with 60 mm master faders and 1/4-inch TRS main bus inserts.
• 2-Track RCA I/O — Unbalanced RCA inputs for playback source integration; RCA outputs for stereo recording to an external device.
• Compact and Lightweight — 95 mm H x 328 mm W x 370 mm D, 3.9 kg; portable enough for rehearsal transport and utility deployment.
• Internal Switch-Mode Power Supply — Accepts 100–240VAC at 50/60 Hz via IEC connector; no external power brick required.

Technical Specifications
