Meyer Sound MM-4XP EN3 5-pin female to pigtail, Black - 28.163.009.01
Product Overview
This Meyer Sound MM-4XP EN3 5-pin female to pigtail cable is the factory interconnect supplied for IntelligentDC loudspeakers fitted with an EN3 connector. It mates to the loudspeaker's SwitchCraft EN3 5-pin male input and breaks out to bare-wire pigtail conductors for splicing to a junction box near the loudspeaker. The pigtail end then receives a longer field cable run back to a Meyer Sound IntelligentDC power supply. This black-jacketed accessory is intended for use with MM-4XP and compatible EN3-equipped loudspeakers.
Product Description
The EN3 5-pin connection carries both 48 V DC power and balanced audio on a single cable: two pins for DC power and three pins for balanced audio (audio shield, audio negative, and audio positive). The pigtail end allows installers to terminate the conductors at a junction box, where a longer composite or separate power-and-audio cable from the MPS-482HP or MPS-488HP power supply is connected. This cable is required for IntelligentDC distribution to EN3-equipped loudspeakers such as the Meyer Sound MM-4XP. For additional Meyer Sound interconnects and loudspeakers, see our Meyer Sound collection.
Key Features
- EN3 5-Pin Female Connector — Mates directly to the SwitchCraft EN3 5-pin male input on MM-4XP and compatible IntelligentDC loudspeakers.
- Pigtail Termination — Bare-wire conductors allow splicing to a junction box for connection to a longer field cable run.
- Combined Power and Audio — Carries both 48 V DC power and balanced audio on a single five-conductor cable.
- Black Jacket — Discreet black cable finish for visible installation locations.
Technical Specifications
| Connector A | SwitchCraft EN3 5-pin female |
| Connector B | Bare-wire pigtail |
| Signal Carried | 48 V DC power (2 pins) plus balanced audio (3 pins) |
| Pin Wiring | Pin 1: DC (–); Pin 2: DC (+); Pin 3: audio shield; Pin 4: audio (–); Pin 5: audio (+) |
| Jacket Color | Black |
| Compatibility | MM-4XP, MM-4XPD, and other EN3-equipped Meyer Sound IntelligentDC loudspeakers |
Specifications sourced from Meyer Sound. Subject to change without notice.
