MaxHub V5550 XBoard V7 Series 55", 4K Flat Panel UHD Display

Product Overview

The MAXHUB V5550 XBoard V7 is a 55-inch interactive flat panel built for conference rooms, corporate meeting spaces, and collaborative training environments. Featuring 4K UHD resolution, a Windows-powered OPS module slot, and MAXHUB's Trident Lens triple-camera system, this interactive display delivers a complete collaboration platform for hybrid meetings and in-room presentations. Its 50-point infrared touch system and 16-microphone array make it a strong choice for teams seeking an all-in-one interactive meeting room display with BYOM flexibility. The V5550 targets mid-size meeting rooms where whiteboarding, wireless screen sharing, and video conferencing must operate from a single device.

Product Description

The MAXHUB V5550 XBoard V7 Series combines a professional 55-inch 4K UHD display with a fully integrated collaboration platform designed for commercial meeting rooms. At 350 nits of brightness with 90% NTSC color gamut and a non-glare, 9H tempered glass surface, the V5550 delivers consistent image quality in typical office lighting conditions. The Trident Lens system integrates three 50-megapixel cameras — one ultra-wide at 99° FOV and two telephoto units with up to 5x hybrid zoom — enabling room view, active speaker tracking, and individual participant framing without an external camera. A 16-microphone array with 180° pickup and up to 15-meter range handles audio for most conference room footprints, supported by AEC, ANC, and AGC processing. The 50-point infrared touch system supports Windows Ink, direct annotation, palm rejection, and handwriting recognition with less than 2.5 ms response time. An OPS module slot accepts optional MT71S or MT71P PC modules running Windows 10 IoT or Windows 11 Pro, while BYOM connectivity is available via USB-C with DisplayPort 1.2 input and HDMI IN. MAXHUB Share software supports Miracast, AirPlay, Chromecast, and P2P wireless screen sharing. RS-232 and IP control enable integration with Crestron, Extron, and Q-SYS control systems. Compare with the MAXHUB V6550 XBoard V7 65″ or MAXHUB V7550 XBoard V7 75″ for larger room coverage. View the full MAXHUB collection at Creation Networks.

Key Features

• 4K UHD Display — 55-inch ADS panel, 3840×2160 resolution, 350 nits brightness, 1200:1 contrast ratio, 90% NTSC color gamut, ΔE ≤1.5 color accuracy.
• 50-Point Infrared Touch — Intelligent Touchscreen Technology with ≤2.5 ms response, Windows Ink support, palm rejection, and direct annotation on Android and Windows inputs.
• Trident Lens Camera System — Three 50 MP cameras: one 99° ultra-wide and two telephoto with 5x hybrid zoom; supports auto framing, active speaker tracking, and room view.
• 16-Microphone Array — 180° pickup pattern, 0–15 m range, with AEC, ANC, and AGC processing for clear audio in hybrid conference calls.
• Built-In 2.1 Speaker System — 2 × 10W + 20W subwoofer for full-room audio without external speakers.
• OPS Module Slot — Accepts MT71S/MT71P Windows PC modules (12th Gen Intel) for a fully independent Windows 10 IoT or Windows 11 Pro compute experience.
• BYOM via USB-C and HDMI — USB-C IN supports DisplayPort 1.2 input, wireless dongle pairing, and BYOD; HDMI IN ×2 up to 4K@60Hz with HDCP 2.2.
• Wireless Screen Sharing — MAXHUB Share supports Miracast, AirPlay, Chromecast, and P2P connection from Windows, Mac, iOS, and Android devices.
• Control System Integration — RS-232 and IP control with verified compatibility for Crestron, Extron, and Q-SYS.
• Wi-Fi 6 and Bluetooth 5.2 — 802.11ax dual-band (2.4 GHz/5 GHz) wireless networking and BT 5.2 via the PC module.

Typical Applications

• Conference room
• Huddle room
• Training room
• Commercial meeting space
• Multi-purpose room
• Government space

Technical Specifications

Specifications sourced from MaxHub (maxhub.com).

Frequently Asked Questions

Is the V5550 compatible with Microsoft Teams or Zoom?
The V5550 XBoard V7 is not a dedicated Teams Rooms device, but it fully supports Teams, Zoom, and other UC platforms when used with the optional Windows OPS PC module or a BYOM laptop connected via USB-C or HDMI.

Does the V5550 include a PC module?
No. The V5550 ships as a display with an OPS slot. The MT71S or MT71P Windows PC module is sold separately and slides into the OPS slot on the rear of the unit.

What mounting hardware is required?
The V5550 uses a 400×200 mm VESA pattern with M8×25 mm screws. A compatible wall mount (WIB6540A) and mobile stand options are available from MAXHUB and through Creation Networks.

Can the V5550 be connected to a room control system?
Yes. The V5550 supports RS-232 (baud rate 9600) and IP control, and is verified compatible with Crestron, Extron, and Q-SYS control systems.

What wireless screen sharing methods are supported?
MAXHUB Share supports Miracast, AirPlay, Chromecast, and P2P direct connection from Windows, macOS, iOS, and Android devices. A wireless dongle (WT13) is also supported via the USB-C port.

Where can I get warranty support?
The V5550 carries a 3-year manufacturer warranty. For service inquiries, configuration advice, or support, contact Creation Networks directly.
