MaxHub ND43CMA 43" 4K Pro Digital Display

Product Overview

The MAXHUB ND43CMA is a 43" 4K UHD commercial-grade digital signage display engineered for continuous operation in meeting rooms, corporate lobbies, and commercial settings. With a 500-nit non-glare panel, conformal coating for humidity and dust resistance, and 24/7 duty-cycle rating, the ND43CMA delivers consistent image quality in demanding environments. MAXHUB Share wireless screen sharing and MAXHUB Pivot cloud-based device management make it a practical choice for IT-administered digital signage deployments. Crestron Connected and NDI certified, it integrates directly into professional AV control infrastructures.

Product Description

The MAXHUB ND43CMA 43" commercial display is built for environments where reliability and image accuracy are non-negotiable. The VA panel delivers 4K UHD resolution (3840×2160) at 500 nits brightness with a 5000:1 native contrast ratio, making content clearly readable in lit conference rooms and lobbies. The non-glare coating and conformal board coating address the twin challenges of ambient light and environmental contamination common in commercial installs. The ND43CMA operates continuously at 24/7, backed by a rated panel life of 50,000 hours minimum. The built-in Wi-Fi 6 module (SI07B), dual-band 2.4G/5G, supports MAXHUB Share for wireless BYOD screen sharing via Miracast, AirPlay, and Chromecast — up to four simultaneous sources. RS232 and IP control allow integration with room automation systems, and the Crestron Connected certification enables one-touch control via XiO Cloud. NDI decoding support makes it compatible with IP video workflows for broadcast and education environments. For larger deployment needs, consider the MAXHUB ND55CMA 55" display or the MAXHUB ND65CMA 65". Browse the full MAXHUB collection at Creation Networks.

Key Features

• 4K UHD Resolution — 3840×2160 VA panel with 10-bit color (1.07 billion colors) for true-to-life image reproduction in commercial signage applications.
• 500 Nits Brightness — High-output backlight maintains display legibility under ambient light conditions in lobbies, corridors, and lit conference rooms.
• 24/7 Commercial Duty Cycle — Rated for continuous round-the-clock operation with a minimum panel lifetime of 50,000 hours.
• Non-Glare & Conformal Coating — Anti-reflective surface treatment combined with conformal board coating provides protection against humidity, dust, and salt in commercial environments.
• MAXHUB Share Wireless Screen Sharing — Supports BYOD, Miracast, AirPlay, and Chromecast; up to four devices can share simultaneously with sub-90ms latency.
• Crestron Connected Certified — Native integration with Crestron AirMedia and XiO Cloud for one-touch power, input switching, and remote diagnostics without custom programming.
• NDI Certified Decoding — Receives high-quality, low-latency IP video over the network, eliminating HDMI runs in NDI-enabled production and education workflows.
• RS232 / IP Control — Full serial and network control support for integration with third-party room automation and AV control systems.
• Wi-Fi 6 (SI07B Module) — Dual-band 802.11ax wireless module with simultaneous Wi-Fi and hotspot operation for device connectivity in meeting spaces.
• 2×16W Built-In Speakers — Integrated audio eliminates the need for external speaker infrastructure in standard meeting room and signage deployments.

Typical Applications

• Boardroom
• Conference room
• Huddle room
• Commercial meeting space
• Government space
• Training room
• Multi-purpose room

Technical Specifications

Specifications sourced from MaxHub (maxhub.com).

Frequently Asked Questions

Is the ND43CMA compatible with OPS compute modules?
No. The 43" and 55" CMA models do not include an OPS slot. For OPS module compatibility, see the 65" through 98" models in the CMA series.

What VESA mount pattern does the ND43CMA use?
The ND43CMA uses a WIB4722A wall mount bracket. Standard VESA mounting hardware is included. Contact Creation Networks for mount compatibility questions prior to installation.

How does RS232 and IP control work with the ND43CMA?
The display supports both RS232 serial control and IP-based control, enabling integration with Crestron, Extron, Q-SYS, and other third-party control systems for power, input switching, and status monitoring.

What is the duty cycle rating?
The ND43CMA is rated for 24/7 continuous commercial operation with a minimum panel lifetime of 50,000 hours, making it suitable for always-on digital signage and meeting room display applications.

Does it support wireless screen sharing without an OPS PC?
Yes. The built-in Android system with Wi-Fi 6 supports MAXHUB Share, Miracast, AirPlay, and Chromecast for wireless BYOD screen sharing without a connected PC.

What warranty and support are available?
MAXHUB commercial displays carry a manufacturer warranty. For warranty details, installation support, and volume pricing, contact Creation Networks directly.
