Martin Audio CDD6W – 6" Passive Coaxial On-Wall Speaker, Pair (White)

Product Overview

The Martin Audio CDD6W is an ultra-compact passive two-way loudspeaker sold as a matched pair in white (RAL9016), designed for installations requiring full-frequency dynamic performance from a very small wall or ceiling-mounted enclosure. Featuring a 6.5" (165mm) LF / 1" (25mm) HF Coaxial Differential Dispersion driver in a UPM Formi composite enclosure, the CDD6W suits bars, hotel lobbies, museums, convention centres, retail environments, and houses of worship where discreet speaker placement must coexist with consistent audio coverage. It also functions as a fill loudspeaker in distributed systems using larger CDD models. The full Martin Audio CDD range is available at Creation Networks.

Product Description

The CDD6W's Coaxial Differential Dispersion technology projects proportionally more output toward the rear of the listening area to counteract SPL attenuation with distance, producing more even front-to-back coverage than speakers with fixed symmetric dispersion patterns. The CDD driver achieves point-source summation of the LF and HF sections at the crossover frequency, eliminating off-axis tonal variation in the crossover region. A static waveguide integrated within the driver assembly maintains the dispersion pattern through the high-frequency range — preventing the progressive HF beaming that narrows the effective coverage of standard coaxial designs as frequency rises. The curved UPM Formi composite enclosure supports both landscape (horizontal) and portrait (vertical) orientations, with the user-rotatable drive unit adjustable in the field after removing the screw-free perforated steel grille. Optional wall and ceiling brackets accommodate flexible surface-mount positioning. Combined with a Martin Audio SX subwoofer, the CDD6W extends into a compact full-range music system capable of higher SPL levels than the satellite alone provides. As a full-range passive two-way system, the CDD6W should be used with a compatible system controller providing appropriate limiter settings. The Martin Audio DX4.0 controller and iKON amplifier provide factory DSP and FIR presets for optimized performance and integrated limiter protection. The CDD6W can be supplied in any RAL colour to order for branded or project-specific installations. The black variant is the CDD6B. All CDD products are available at creationnetworks.net.

Key Features

• Sold as a Matched Pair — Each order includes two CDD6W units for stereo or matched distributed coverage.
• 6.5" Coaxial Differential Dispersion Driver — Point-source LF/HF summation with Differential Dispersion coverage pattern for even front-to-rear SPL distribution.
• Static HF Waveguide — Maintains dispersion pattern through high frequencies, preventing HF beaming in the upper frequency range.
• Ultra-Compact UPM Formi Enclosure — Rigid composite construction in a minimal form factor for discreet architectural installations.
• User-Rotatable Drive Unit — Field-selectable horizontal or vertical dispersion orientation without tools after grille removal.
• Screw-Free Perforated Steel Grille — Tool-free grille removal for drive unit rotation and service access.
• Optional Wall and Ceiling Brackets — Flexible surface mounting via standard Martin Audio bracket accessories.
• Subwoofer Compatibility — Pairs with Martin Audio SX subwoofers to extend low-frequency response for full-range music program applications.
• DX4.0 and iKON Amplifier Compatibility — Factory DSP and FIR presets for optimized frequency response and integrated limiter protection.
• White (RAL9016) Finish with Custom RAL Option — Standard white finish for light architectural surfaces; available in any RAL colour to order.

Typical Applications

• House of worship
• Commercial meeting space
• Multi-purpose room
• Training room
• All-hands room

Technical Specifications

Frequently Asked Questions

Is the CDD6W sold individually or as a pair?

The CDD6W is sold as a matched pair. Each order includes two CDD6W loudspeakers.

What controller or amplifier is required?

The CDD6W should be used with a compatible system controller providing appropriate limiter settings. Martin Audio recommends the DX4.0 networked system controller with an iKON amplifier, which include factory-tuned DSP and FIR presets for the CDD6 series.

Can the CDD6W be used as a fill speaker in a larger CDD system?

Yes. The CDD6W integrates with larger CDD models as a fill or delay-zone speaker, with the matching CDD driver technology ensuring tonal continuity across all positions in the distributed system.

How does the CDD6W differ from the CDD6B?

The CDD6W and CDD6B are acoustically identical. The CDD6W ships in white (RAL9016) and the CDD6B in black (RAL9005). Both are sold as pairs at Creation Networks.

Can the CDD6W work as a standalone music system?

With the addition of a Martin Audio SX series subwoofer, the CDD6W can function as a compact full-range music system capable of reproducing music program at levels beyond what the satellite alone provides. For background music applications, the CDD6W may not require a subwoofer depending on the venue's bass expectations.

Is a custom finish available?

Yes. Martin Audio can supply the CDD6W in any RAL colour to order. Contact Creation Networks for lead times and pricing on non-standard finishes.

What warranty applies?

Martin Audio products carry a standard manufacturer warranty. Contact Creation Networks at creationnetworks.net for warranty terms and dealer support.
