Martin Exterior Projection 1000 – IP66 LED Gobo Projector, EU

Product Overview

The Martin Exterior Projection 1000 is an IP66-rated LED gobo projector built for large-scale outdoor image and logo projection across architectural, government, and commercial environments. This Martin Exterior Projection 1000 outdoor projector combines a 440 W LED engine with a wide motorized zoom and dynamic effects to throw sharp textures and patterns over long distances. It is engineered for permanent installation in demanding weather, with a vandal-resistant housing and corrosion-rated finish. The fixture suits facade lighting, signage, and feature projection where reach and image quality matter. This unit ships in the EU standard finish.

Product Description

The Exterior Projection 1000 is an advanced IP66-rated LED projector that pairs a 440 W LED engine with dynamic effects and rugged weatherproofing. Luminous output scales with zoom, producing 11,500 lumens at 10 degrees, 15,000 lumens at 16 degrees, and 16,800 lumens at 40 degrees. The motorized zoom covers a range of 10 to 43.5 degrees, allowing the projected image size to be matched to the target surface and throw distance. The fixture is rated for a 20,000-hour lamp life, equivalent to roughly seven years of use at eight hours per day. It operates across an ambient temperature range of -30 degrees C to 45 degrees C. The robust aluminum housing carries an IK08 impact rating and an IP66 ingress rating, and its surface treatment complies with the ISO 12944 / C5-M corrosion protection standard for high-corrosivity and marine environments. CMY color mixing supports a wide palette for textures, patterns, and logo projection. The combination of high output, sharp optics, and weather resistance makes the fixture suitable for permanent exterior installations where great reach over large distances is required. This product is supplied in the EU standard finish.

Key Features

• 440 W LED engine — A 440 W LED light engine drives high output for long-throw exterior projection.
• Variable luminous output — Output ranges from 11,500 lumens at 10 degrees to 16,800 lumens at 40 degrees of zoom.
• Wide motorized zoom — A 10 to 43.5 degree zoom range lets the image be sized to the surface and throw distance.
• CMY color mixing — Full CMY color mixing supports textures, patterns, and logo projection in a wide range of colors.
• IP66 and IK08 rated — The aluminum housing carries an IP66 ingress rating and an IK08 impact rating for outdoor durability.
• Corrosion protection — The surface treatment complies with the ISO 12944 / C5-M corrosion standard for high-corrosivity and marine sites.
• Wide operating range — The fixture operates from -30 degrees C to 45 degrees C for year-round outdoor use.
• Long lamp life — A 20,000-hour lamp life equates to about seven years at eight hours of daily use.

Typical Applications

• Government space
• Commercial meeting space
• House of worship
• Auditorium
• Broadcast studio

Technical Specifications

Frequently Asked Questions

Is the Exterior Projection 1000 suitable for permanent outdoor installation? Yes. With an IP66 ingress rating, IK08 impact rating, ISO 12944 / C5-M corrosion-rated finish, and a -30 to 45 degrees C operating range, it is designed for permanent exterior use.

How large an image can it project? The motorized zoom ranges from 10 to 43.5 degrees, so image size depends on the selected zoom and the throw distance to the target surface.

How does it integrate into an AV or control system? The fixture supports dynamic effects and CMY color mixing for control through standard lighting systems. Contact Creation Networks for control and integration guidance.

What is the expected service life? The fixture is rated for a 20,000-hour lamp life, approximately seven years at eight hours of daily operation.

Is the fixture covered by a warranty? The fixture is covered by Martin by HARMAN's manufacturer warranty; contact Creation Networks for terms.

Where can I get installation and support assistance? Creation Networks can advise on mounting, projection alignment, and integration for the Exterior Projection 1000.
