Martin VDO Fatron 20 320mm – IP65 LED Video Batten, Cardboard
Product Overview
The Martin VDO Fatron 20 320mm is a compact IP65 outdoor-rated LED video and graphic batten with a 20mm pixel pitch. It serves rental, broadcast, and architectural users building creative video surfaces and pixel-mapped graphic walls. Primary search terms include VDO Fatron 20, Martin IP65 LED video batten, and 320mm pixel batten.
Product Description
The VDO Fatron 20 is built on an extruded matte-black aluminum profile and carries a 4 x 16 RGB LED array at a 20mm center-to-center pixel pitch on the 320mm model. It is rated IP65 for indoor and outdoor use and is RoHS compliant. In calibrated mode the fixture delivers a luminous intensity of 500 cd per meter and a luminous output of 1500 lumens per meter, with a 6500 Kelvin color temperature and a 120 by 120 degree viewing angle. The LED refresh rate is 1001 Hz in Standard Mode and 4004 Hz in High Refresh Mode for camera work. Color resolution is 16-bit per color over P3 and 8-bit per color over DMX. The fixture runs on the Martin P3 ecosystem through a P3 PowerPort, or directly via DMX, and supports P3, DMX, Art-Net, and sACN control with pixel-level addressing. Power and data run together over a 6-pin IP66-rated BBD connector that is hot-plug compatible, with a nominal 48 VDC input. Cooling is by convection. This SKU denotes the 320mm fixture supplied in cardboard packaging. The part number is 90357691HU.
Key Features
- IP65 construction — The matte-black extruded aluminum batten is rated IP65 for indoor and outdoor use.
- 20mm pixel pitch — The 320mm model carries a 4 x 16 RGB LED array at 20mm center-to-center spacing.
- Calibrated output — In calibrated mode the fixture produces 1500 lumens per meter and 500 cd per meter at 6500 K.
- High refresh option — The LED refresh rate reaches 4004 Hz in High Refresh Mode for on-camera use.
- Flexible control — It supports P3, DMX, Art-Net, and sACN with 16-bit per color over P3 and pixel-level addressing.
- Combined power and data — A 6-pin IP66-rated BBD connector carries 48 VDC power and data and is hot-plug compatible.
- Interchangeable optics — The fixture accepts the full range of clip-on VDO Fatron diffusers and lenses.
Typical Applications
- Broadcast studio
- Auditorium
- House of worship
- Multi-purpose room
Technical Specifications
| Specification | Detail |
|---|---|
| Part Number | 90357691HU |
| Pixel Pitch | 20.00 mm center-to-center |
| LED Array | 4 x 16 RGB |
| Viewing Angle | 120° x 120° (half-peak) |
| Luminous Intensity (calibrated) | 500 cd per meter |
| Luminous Output (calibrated) | 1500 lumen per meter |
| Color Temperature | 6500 K |
| LED Refresh Rate | 1001 Hz (Standard) / 4004 Hz (High Refresh) |
| Color Resolution | 16-bit per color (P3) / 8-bit per color (DMX) |
| LED Lifetime | 50,000 hours to >70% output |
| Dimensions | 320 mm L x 80 mm W; 28 mm H without front, 48 mm H with standard front |
| Weight | 0.85 kg (1.9 lb) without front; 0.95 kg (2.1 lb) with standard front |
| Power Consumption | Max 20 W (all LEDs at full) |
| Input Voltage | 48 VDC nominal ±4% |
| Protection Rating | IP65 |
| Control | P3, DMX, Art-Net, sACN; pixel-level; RDM-compliant |
| Connector | 6-pin BBD, IP66, hot-plug compatible |
| Cooling | Convection |
| Construction | Extruded aluminum, matte black |
Frequently Asked Questions
How is the VDO Fatron 20 powered? It accepts a nominal 48 VDC input through a Martin P3 PowerPort or compatible 48 VDC supply, with power and data carried on a single BBD connector.
What control protocols does it support? It supports P3, DMX, Art-Net, and sACN, with 16-bit per color over P3 and pixel-level addressing.
Can it be used outdoors? Yes. The fixture is rated IP65 for indoor and outdoor use.
Are diffusers included? A standard square diffuser front ships with the fixture, and additional clip-on round, flat, square, and NoBlend diffusers are available separately.
What does "in cardboard" mean? It indicates the standard cardboard-box packaging SKU of the 320mm fixture.
Is this product covered by a warranty? Yes. It is covered by Martin by HARMAN's manufacturer warranty; contact Creation Networks for terms.
