Martin MAC Aura PXL – High-Output LED Wash with 141-Pixel Aura

Product Overview

The Martin MAC Aura PXL is a high-output LED wash moving head built for pixel mapping, combining a 10,500-lumen 19 x 40W RGBW beam with a 141-pixel Aura backlight. Nineteen individually controllable beam pixels and 141 mapped Aura pixels make this high-output wash moving head a powerful canvas for video and effect content. With Art-Net, sACN, and Martin P3 over Ethernet, it integrates into advanced networked control for concerts, broadcast, and large installations.

Product Description

The MAC Aura PXL pushes the Aura platform to its highest output and deepest pixel control. A 19 x 40W RGBW beam delivers 10,500 lumens for large stages and long throws, and the fixture is engineered for pixel mapping with 19 individually controllable beam pixels plus a 141-LED pixel-mapped Aura backlight. RGBW color mixing produces vibrant saturated colors, pastels, and white tones, with Beam and Aura color temperature adjustable from 2,000 K to 10,000 K. A precise, silent 6° to 59° zoom covers tight aerial beams through broad even washes. More than 150 built-in FX macros provide foreground color, background color, speed, and direction control, while Martin P3 video mapping addresses both beam and Aura pixels with variable crossfade between DMX and video. Connectivity includes Ethernet in and thru with Art-Net, sACN, and Martin P3, plus RDM over both DMX and Art-Net. A battery-powered base control panel allows configuration without power. The 15.60 kg head measures 410 x 489 x 232 mm and is also offered in a SiP flightcase configuration for protected touring transport, making it a versatile, high-impact wash for concert, broadcast, rental, and installation use.

Key Features

• 10,500-Lumen RGBW Output — A 19 x 40W RGBW beam delivers high output for large stages and long throws.
• Built for Pixel Mapping — 19 beam pixels plus 141 individually controllable Aura pixels enable detailed video and effect mapping.
• 6°–59° Silent Fast Zoom — A wide, quiet zoom covers tight beams through broad washes.
• P3 Video Mapping — Map video to beam and Aura pixels with crossfade between DMX and video control.
• Networked Control — Ethernet in and thru with Art-Net, sACN, and Martin P3, plus RDM over DMX and Art-Net.
• 150+ Built-In FX Macros — Foreground/background color, speed, and direction control streamline programming.
• Variable Color Temperature — Beam and Aura CTC from 2,000 K to 10,000 K for accurate white matching.

Typical Applications

• Concert and Touring Production — High output and pixel mapping for large-scale stage looks.
• Broadcast and Live Events — Pixel beam and Aura effects deliver dynamic, camera-ready visuals.
• Rental and Staging — Feature-rich, networkable wash for premium rental inventories.
• Auditorium and Arena — Bright, high-impact wash coverage for large venues.
• House of Worship — Large-format wash and eye-candy with accurate color.

Technical Specifications

Specifications sourced from Martin (Harman Professional).

Frequently Asked Questions

What makes the MAC Aura PXL 'PXL'?
It is built for pixel mapping, with 19 individually controllable beam pixels and 141 pixel-mapped Aura LEDs for detailed video and effect content.

How bright is it?
It produces 10,500 lumens of RGBW output from a 19 x 40W beam engine.

What control protocols does it support?
DMX and RDM plus Art-Net, sACN, and Martin P3 over Ethernet (in and thru), including RDM over Art-Net.

Can it be used for video mapping?
Yes. Martin P3 video mapping addresses both beam and Aura pixels with variable crossfade between DMX and video control.

What is the difference between the standard and SiP versions?
The fixture is identical; the SiP version ships in Stay-in-Place flightcase foam packaging for touring transport and storage.

What warranty and support are available?
Martin fixtures carry the manufacturer's limited warranty, and Creation Networks supports integrators with specification and procurement.
