Martin MAC Aura PXL White – High-Output LED Wash Moving Head
Product Overview
The Martin MAC Aura PXL White is the white-finish version of Martin's high-output, pixel-mapping LED wash moving head, combining a 10,500-lumen 19 x 40W RGBW beam with a 141-pixel Aura backlight. Nineteen individually controllable beam pixels and 141 mapped Aura pixels make this high-output wash moving head a powerful canvas for video and effect content, in a white chassis that blends into light-colored environments. With Art-Net, sACN, and Martin P3 over Ethernet, it integrates into advanced networked control for concerts, broadcast, and large installations.
Product Description
The MAC Aura PXL White is functionally identical to the standard MAC Aura PXL, differing only in its white housing finish, and pushes the Aura platform to its highest output and deepest pixel control. A 19 x 40W RGBW beam delivers 10,500 lumens for large stages and long throws, and the fixture is engineered for pixel mapping with 19 individually controllable beam pixels plus a 141-LED pixel-mapped Aura backlight. RGBW color mixing produces vibrant saturated colors, pastels, and white tones, with Beam and Aura color temperature adjustable from 2,000 K to 10,000 K. A precise, silent 6° to 59° zoom covers tight aerial beams through broad even washes. More than 150 built-in FX macros provide foreground color, background color, speed, and direction control, while Martin P3 video mapping addresses both beam and Aura pixels with variable crossfade between DMX and video. Connectivity includes Ethernet in and thru with Art-Net, sACN, and Martin P3, plus RDM over both DMX and Art-Net. A battery-powered base control panel allows configuration without power. The 15.60 kg head measures 410 x 489 x 232 mm, and its white finish is ideal where fixtures should blend into light-colored trusses, ceilings, and architectural environments.
Key Features
- 10,500-Lumen RGBW Output — A 19 x 40W RGBW beam delivers high output for large stages and long throws.
- Built for Pixel Mapping — 19 beam pixels plus 141 individually controllable Aura pixels enable detailed video and effect mapping.
- 6°–59° Silent Fast Zoom — A wide, quiet zoom covers tight beams through broad washes.
- P3 Video Mapping — Map video to beam and Aura pixels with crossfade between DMX and video control.
- Networked Control — Ethernet in and thru with Art-Net, sACN, and Martin P3, plus RDM over DMX and Art-Net.
- 150+ Built-In FX Macros — Foreground/background color, speed, and direction control streamline programming.
- White Housing Finish — White chassis blends into light-colored trusses, ceilings, and architectural environments.
Typical Applications
- Concert and Touring Production — High output and pixel mapping for large-scale stage looks.
- Broadcast and Live Events — Pixel beam and Aura effects deliver dynamic, camera-ready visuals.
- Rental and Staging — Feature-rich, networkable wash for premium rental inventories.
- Auditorium and Arena — Bright, high-impact wash coverage for large venues.
- House of Worship — Large-format wash and eye-candy with accurate color, in a white finish to blend into interiors.
Technical Specifications
| Housing color | White |
| Beam light source | 19 x 40 W RGBW LED (pixelated) |
| Aura light source | 141 x 0.3 W RGB LED (pixel-mapped) |
| Fixture luminous output | 10,500 lumens RGBW |
| Zoom range | 6° – 59° |
| Beam / Aura color temperature | Variable 2,000 – 10,000 K |
| Color mixing | RGBW; full-gamut color |
| Effects | 150+ FX macros; 19 beam pixels; 141 Aura pixels; P3 video mapping |
| Control / protocols | DMX/RDM, Art-Net, sACN, Martin P3; RDM over DMX and Art-Net; Ethernet in & thru |
| Pan / Tilt | 16-bit control |
| Dimensions | 410 x 489 x 232 mm |
| Weight | 15.60 kg (34.39 lbs) |
Specifications sourced from Martin (Harman Professional).
Frequently Asked Questions
How does the White version differ from the standard MAC Aura PXL?
It is functionally identical and shares all specifications; only the housing color differs, with a white finish to blend into light-colored trusses and ceilings.
What makes the MAC Aura PXL 'PXL'?
It is built for pixel mapping, with 19 individually controllable beam pixels and 141 pixel-mapped Aura LEDs for detailed video and effect content.
How bright is it?
It produces 10,500 lumens of RGBW output from a 19 x 40W beam engine.
What control protocols does it support?
DMX and RDM plus Art-Net, sACN, and Martin P3 over Ethernet (in and thru), including RDM over Art-Net.
Can it be used for video mapping?
Yes. Martin P3 video mapping addresses both beam and Aura pixels with variable crossfade between DMX and video control.
What warranty and support are available?
Martin fixtures carry the manufacturer's limited warranty, and Creation Networks supports integrators with specification and procurement.
