Marantz Professional AVS All-In-One Broadcasting System

The Marantz AVS is an all-in-one broadcast system that offers the live streamer professional components in a compact, free-standing array.

The AVS features a full HD webcam compatible with H.264 video compression, a high-quality 48kHz/16-bit USB condenser boundary microphone conveniently integrated into the base of the unit, and an LED light ring, daylight-balanced, with both cool and warm filter accessories for the look of a studio production. The Marantz AVS is a unique, all-in-one broadcast tool that is designed for live-streaming, video calling and gaming applications. It is compact and simple, perfect on a desktop, and the lightweight design makes it portable enough to take on location.

To make the system truly self-contained and capable of handling any streaming/podcast task without the need for additional equipment, the AVS has a high-speed USB-C computer output for low latency and an internal USB hub. There is even an onboard headphone amplifier so audio monitoring is simple. Everything the demanding streaming/broadcasting enthusiast needs is right here, in one convenient, high-performance package.

Features

Specs

Camera:
Fixed-focus
CMOS Sensor
Diagonal field of view: 70 °
Optical resolution: 2MP native
Full HD 1080p video (up to 1920 x 1080 pixels) recording
Frame rate: 30 fps/1080p, 30 fps/720p
H.264 video compression
ON/OFF switch
Automatic low-light and white balance correction
Compatible with Windows® XP, 7, 8, 10, Mac OS X, LINUX, Android
Operates in USB Video Device Class (UVC) mode
USB 2.0 – Class 2 Compliant Driver

Boundary Microphone:
Element: Back electret condenser
Polar pattern: Half-cardioid (cardioid in hemisphere above mounting surface)
Open Circuit Sensitivity: -44dB ± 3dB (0db = 1V/Pa @ 1KHZ)
Output impedance: 2.2 kΩ ± 30% (@ 1kHz)
Sample rate: 32 kHz / 44.1 kHz / 48 kHz @16-bit
Frequency response: 150 Hz - 10 kHz
Signal-to-Noise Ratio: >60 dB (1kHz @ 1% THD)
Max SPL: 100 dB
ON/OFF switch

Headphone Amplifier:
Frequency Response: 20 Hz – 20 kHz
Output power: 130mW
Level control
3.5mm stereo output
Mix control to mix microphone audio with USB audio input
LED Light Ring
4" dimmable LED light ring
(30) wide-angle white LEDs @ 5600K
(3) accessory filters
Diffused daylight
Cool
Warm
USB

USB 1 & 2: (2) Type A USB 3.0, 0.75A total available current between two ports for powering devices
To PC: (1) USB-C connector / USB 3.0 connection
USB Audio In: Class 2 compliant speaker device for audio to be monitored in headphone output – set by user in the computer

Microphone Auxiliary Output
Fixed line-level output on 3.5mm TRS jack

Power
AC-DC power supply
100 ~ 240 VAC compatible
12 VDC @ 1 amp output

Dimensions (width x depth x height): .39” x 6.26” x 19.1” (188 x 159 x 485mm)
Weight: 2.29 lbs (1.04 kg)
