Magewell Pro Convert for NDI to AIO – Standalone NDI Decoder HDMI SDI Output

Product Overview

The Magewell Pro Convert for NDI to AIO is a standalone IP video decoder that converts NDI, SRT, RTSP, RTMP, HLS, and MPEG-TS streams into simultaneous HDMI and SDI baseband outputs for integration with conventional AV distribution equipment. Designed for commercial AV integrators and IT/facilities managers working in IP-based media networks, the AIO (All-In-One) output model eliminates the need for separate HDMI-only or SDI-only decoder units by delivering both signals from a single compact device. It supports NDI High Bandwidth, NDI HX, NDI HX2, and NDI HX3 decoding up to NDI SDK version 6.3, making it forward-compatible with current NDI infrastructure. The device is suited to boardrooms, conference rooms, government spaces, and broadcast studios where IP video sources must be presented on HDMI displays or routed into SDI-based production systems.

Product Description

The Pro Convert for NDI to AIO (SKU: 642100000) connects to a standard GigE network port and decodes NDI streams — including NDI High Bandwidth, NDI HX, HX2, and HX3 — as well as SRT, RTSP, RTMP Pull/Push, HLS, HTTP, and MPEG-TS over UDP and RTP, outputting the decoded signal simultaneously to both its HDMI 1.4 port and SD/HD/3G-SDI BNC connector. Maximum output is 1920x1080p60 on both interfaces, with full support for 48kHz 8-channel audio. The SDI output supports SD (ST 259), HD (ST 292), 3Ga/3Gb/3Gb-DL/3Gb-DS (ST 425) standards and can drive a signal up to 130 meters (427 feet).

Configuration and monitoring are handled through a browser-based Web GUI accessible over HTTP, supporting IE, Edge, Firefox, Chrome, Safari, and Opera. The device also provides HTTP APIs for custom control system integration, with published Crestron and Q-SYS plugins available for AV control environments. IEEE 802.3af PoE support on the Ethernet port allows deployment without a local power supply in PoE-capable installations. An on-board rotary DIP switch (0–F) and MENU/SELECT buttons provide local control without network access. The device can also be registered with Magewell Control Hub for centralized fleet management across multi-room or campus-wide deployments. NDI device discovery across network segments is supported natively, and the compact form factor (100.9mm x 60.2mm x 23.3mm) includes a ¼-20 threaded mounting hole and an included L-bracket for flexible physical installation.

Key Features

• Simultaneous HDMI and SDI Output (AIO) — Decodes a single IP stream and delivers it to both HDMI 1.4 and SD/HD/3G-SDI outputs at the same time, serving dual-display or hybrid AV/broadcast environments.
• NDI 6.3 Support — Compatible with NDI High Bandwidth, NDI HX, NDI HX2, and NDI HX3 decode modes; updated to NDI SDK version 6.3 for current infrastructure compatibility.
• Multi-Protocol IP Video Input — Decodes SRT, RTSP, RTMP Pull/Push, HLS, HTTP, and MPEG-TS over UDP/RTP in addition to NDI, providing flexibility across mixed IP video environments.
• H.264, H.265, and SpeedHQ Decoders — Hardware decode support for SpeedHQ (NDI native), H.264, and H.265 video codecs; AAC and MP3 audio decoders included.
• 8-Channel Audio Output — Outputs 48kHz, 16-bit, 8-channel audio on both HDMI and SDI interfaces, supporting multi-channel audio distribution in commercial AV systems.
• IEEE 802.3af PoE — Powers the device directly from a PoE-capable network switch, eliminating the need for a local power outlet in many installation scenarios.
• Browser-Based Web GUI — Provides real-time device status, signal configuration, OSD settings, audio gain/mapping, deinterlacing, and firmware updates through any major web browser.
• HTTP APIs + Crestron and Q-SYS Plugins — Enables integration into Crestron and Q-SYS control systems via published plugins, and supports custom integration through documented HTTP APIs.
• Cross-Segment NDI Discovery — Discovers NDI sources across network segments, supporting distributed IP video architectures with multiple VLANs or subnets.
• Magewell Control Hub Compatible — Can be registered with Control Hub for centralized management, monitoring, and configuration of multiple decoder units.
• SDI Cable Drive up to 130m — 3G-SDI output supports signal transmission distances up to 130 meters (427 feet), appropriate for larger venue distributions.
• Compact, Mountable Form Factor — Includes a ¼-20 threaded mounting hole and L-bracket; rack-mount accessories available separately for 1RU rack integration via Magewell's rackmount shelf.

Typical Applications

• Boardroom and executive conference room IP video display systems
• Conference room and commercial meeting space NDI-to-HDMI/SDI conversion
• Government space and multi-purpose room AV integration
• Broadcast studio NDI-to-SDI signal bridging and distribution
• House of worship IP video distribution to display walls and confidence monitors
• Training room and all-hands room presentation display from IP video networks
• Auditorium display and overflow room video distribution

Technical Specifications

Frequently Asked Questions

What NDI versions does the Pro Convert for NDI to AIO support?
The device supports NDI High Bandwidth, NDI HX, NDI HX2, and NDI HX3 decode modes via the NDI SDK 6.3. Note: NDI HX1 device discovery is not supported in firmware version V1.2.237 and later.

Can the HDMI and SDI outputs run simultaneously?
Yes. The AIO (All-In-One) designation specifically refers to the device's ability to decode a single IP stream and output it simultaneously to both the HDMI 1.4 and 3G-SDI ports, at up to 1920x1080p60 on each.

Does the device support Power over Ethernet (PoE)?
Yes. The Ethernet port is IEEE 802.3af PoE compliant, allowing the device to be powered directly from a compatible PoE switch without a local power outlet. A USB 2.0 power adapter is also included for non-PoE environments.

How is the device configured and monitored?
Configuration is done through a browser-based Web GUI accessible from any major browser over the local network. HTTP APIs are available for custom control system integration, and Crestron and Q-SYS plugins are available for download from Magewell's website. The device can also be managed centrally via Magewell Control Hub.

Can this decoder discover NDI sources across different network segments or VLANs?
Yes. The Pro Convert for NDI to AIO supports NDI device discovery across network segments, which is necessary in multi-VLAN enterprise or campus network architectures. Multiple NDI discovery servers can be configured.

Is the device compatible with Crestron or AMX control systems?
Yes. Magewell publishes Crestron SIMPL+ module plugins (v1.0.0.0) for the Pro Convert decoder family. HTTP APIs are also documented for integration with AMX, Extron, or other control system platforms.

What rack-mount options are available?
The device includes an L-bracket for surface or panel mounting and has a ¼-20 threaded hole. For 1RU rack installation, Magewell offers a separate 1RU Rackmount Shelf. A module-type variant (Pro Convert for NDI to AIO Module) is also available for use with the Magewell Modator 2U chassis for high-density deployment.

What is the warranty on this product?
Magewell does not publish a separate warranty term for the Pro Convert series on their spec sheet. For warranty coverage details, contact Creation Networks at the time of purchase. Magewell provides direct technical support through their ticket system at tickets.magewell.com.
