LUXUL PI-25 Series Single Port 2.5 Gigabit PoE/PoE+ Injector 30W

Product Overview

The Luxul PI-25 Series Single Port 2.5 Gigabit PoE/PoE+ Injector delivers up to 30 watts of IEEE 802.3at-compliant power to a single network device over a standard Ethernet cable, making it a practical solution for commercial AV deployments where a PoE-capable switch is not available or practical. As a 2.5 Gigabit PoE injector, the PI-25 supports network speeds up to 2.5 Gbps, ensuring sufficient bandwidth headroom for high-throughput AV endpoints such as wireless access points, IP cameras, VoIP phones, and AV-over-IP encoders or decoders. The built-in power supply eliminates the need for an external adapter, and the compact form factor allows installation in tight equipment spaces. Certified to FCC, CE, RoHS, and UKCA standards, the PI-25 is appropriate for professional commercial AV and IT infrastructure environments.

Product Description

The Luxul PI-25 is a single-port midspan power injector designed for AV integrators and IT professionals who need to add PoE+ power to a single network device without replacing existing switching infrastructure. Operating as an IEEE 802.3at compliant single port PoE+ injector, the PI-25 delivers up to 30 watts over Category 5e or better cabling at distances up to 328 feet (100 meters), covering the full standard Ethernet run length. The 2.5 Gigabit speed capability (10/100/1000/2500 Mbps auto-negotiation) makes this injector forward-compatible with 2.5G network devices, ensuring the unit will not become a bottleneck as AV endpoints migrate to higher-throughput standards. The built-in power supply with included power cord means the PI-25 ships ready to deploy with no additional accessories required. Its compact dimensions — 3.94 in L x 2.3 in W x 1.31 in H — allow placement in equipment racks, on shelves, or in equipment closets with minimal footprint. The unit weighs just 0.34 lbs, further simplifying installation in locations with limited mounting options. For AV system designers specifying network infrastructure for AV-over-IP systems, digital signage networks, or PTZ camera installations, the PI-25 provides a cost-effective per-port power solution when deploying isolated PoE devices on non-PoE switches or legacy network segments. The combination of 2.5G throughput capacity and full PoE+ power output positions this injector as a capable midspan solution for current and next-generation commercial AV network endpoints.

Key Features

• IEEE 802.3at PoE+ Compliance — Delivers up to 30 watts per port, sufficient for PoE+ devices including wireless access points, IP cameras, and AV-over-IP endpoints.
• 2.5 Gigabit Ethernet Speed — Supports 10/100/1000/2500 Mbps auto-negotiation for compatibility with both legacy and next-generation 2.5G network devices.
• Built-In Power Supply — Integrated PSU with included power cord eliminates the need for external power adapters and simplifies deployment.
• Up to 328 ft (100 m) Range — Full IEEE 802.3 standard cable distance support over Cat5e or better cabling.
• Compact Form Factor — Dimensions of 3.94 x 2.3 x 1.31 in allow installation in tight rack or closet spaces without occupying rack unit space.
• Single-Port Midspan Design — Ideal for adding PoE+ power to one device on a non-PoE switch without requiring infrastructure replacement.
• Broad Regulatory Certification — Certified to CB Report, CE, CE-EMC, CE-LVD, FCC, IC, RoHS, and UKCA standards for use in commercial environments across multiple markets.

Technical Specifications
