The Lightware UBEX-Pro20-HDMI-F100 RED is a fiber-based AV-over-IP receiver endpoint device in the Lightware UBEX Pro20 series, designed for 10G optical network distribution of uncompressed HDMI 2.0 video in large-scale commercial AV installations. As a RED (Receiver Endpoint Device) unit, it connects to a 10G fiber network switch and decodes a single HDMI 2.0 output stream at up to 4K UHD resolution for delivery to a connected display. The UBEX Pro20 series is built on Lightware’s AVX technology platform and is compatible with SDVoE-compliant infrastructure, making it deployable alongside existing 10G AV-over-IP ecosystems in auditoriums, broadcast studios, and large enterprise campuses. Available from Creation Networks for commercial AV integrators.

Product Description

The UBEX-Pro20-HDMI-F100 RED connects to a 10G fiber switch port and outputs an HDMI 2.0 signal to the local display, functioning as the receive node in a UBEX Pro20 AV-over-IP distribution system. The F100 designation indicates the fiber optical interface, providing immunity to electromagnetic interference over long campus or building fiber runs where copper 10G would be impractical. The RED unit receives video, audio, control, and Ethernet data from the network, presenting a clean HDMI 2.0 output to the display with low latency appropriate for live video and presentation workflows.

The UBEX Pro20 system scales from point-to-point connections to large matrix configurations by adding transmitter endpoints and a 10G fiber switch, with no dedicated matrix frame required. This network-centric architecture allows I/O expansion by simply adding endpoint units without replacing existing infrastructure. Control is managed via the network, and the unit integrates with Lightware’s management software for endpoint configuration, EDID management, and status monitoring. For large auditoriums, broadcast facilities, and multi-building campuses, the UBEX Pro20 RED provides a reliable, scalable fiber receive endpoint.

Key Features

• 10G Fiber Network Interface — Connects to 10G optical switch infrastructure for EMI-immune, long-distance AV signal distribution across buildings and campuses.
• HDMI 2.0 Output — Delivers uncompressed HDMI 2.0 video to the connected display at up to 4K UHD resolution.
• SDVoE/AVX Platform Compatibility — Built on Lightware’s AVX technology, compatible with SDVoE-compliant 10G switching infrastructure.
• Networkless Matrix Scaling — Adds display endpoints without replacing matrix frames; capacity expands by adding switch ports and endpoint units.
• Low Latency AV Distribution — Appropriate for live production, presentation, and monitoring applications where frame delay is a system concern.
• HDCP Compliance — Supports HDCP for content-protected source distribution across the network.
• Advanced EDID Management — Manages display EDID profiles across the network to control source output resolution.
• Centralized Management — Integrates with Lightware management software for monitoring, configuration, and control of all UBEX endpoints on the network.

Typical Applications

• Auditorium and large venue multi-display AV distribution
• Broadcast studio monitor wall and multiviewer systems
• Conference room and all-hands room network AV endpoints
• Government and enterprise campus-wide display networks
• Training room distributed display systems
• House of worship multi-zone video distribution

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What does the RED designation mean?

RED stands for Receiver Endpoint Device. It is the display-side unit in the UBEX Pro20 AV-over-IP system, receiving the video stream from the network and outputting it over HDMI 2.0 to the connected display.

What network switch is required?

The UBEX-Pro20-HDMI-F100 RED requires a 10G optical network switch. The switch is not included. Contact Creation Networks for compatible 10G switch recommendations.

What is the matching transmitter unit?

The UBEX Pro20 system uses UBEX transmitter endpoint devices (TED) on the source side. Contact Creation Networks for the appropriate UBEX-Pro20 TED unit to pair with the F100 RED in your system design.

How does scaling work compared to a traditional matrix switcher?

Instead of a dedicated matrix frame, the UBEX Pro20 uses the 10G network switch as the routing fabric. Adding outputs means adding RED units and switch ports — no frame replacement required. This makes it cost-effective for systems that grow over time.

Is it compatible with non-Lightware SDVoE devices?

The UBEX Pro20 platform is built on Lightware’s AVX technology and is SDVoE-compatible. Interoperability with third-party SDVoE devices should be verified with Lightware or Creation Networks prior to deployment.

What is the maximum fiber run length supported?

Maximum fiber distance depends on the optical transceiver and switch used. The F100 interface supports standard 10G multimode and single-mode fiber distances as determined by the SFP+ optics installed in the switch. Contact Creation Networks for specific fiber distance planning.

Does the unit require a control system?

The UBEX-Pro20-HDMI-F100 RED is manageable via Lightware’s Device Controller software and LW3 protocol. Integration with third-party control systems (Crestron, AMX, Extron) is supported via standard protocols.
