Lightware RAP-B511-EU-W Room Automation Panel (EU, White)

Product Overview

The Lightware RAP-B511-EU-W is a wall-mount room automation panel in EU back-box format, finished in white, that integrates AV signal switching and programmable room control into a single flush-mounted device. It is designed for commercial meeting rooms, boardrooms, and conference facilities across continental Europe where the standard EU 86mm wall plate format is the prevailing electrical installation standard. The panel eliminates the need for a separate rack-mounted control processor, reducing system cost, rack space, and ongoing software licensing overhead.

Product Description

The RAP-B511-EU-W fits a standard EU 86x86mm wall back-box and presents a white capacitive touch button panel flush with the wall surface. HDMI and USB-C inputs on the panel face accept presenter laptop connections directly at the wall, with video, audio, and USB signals processed inside the device. Output is provided over HDMI to a local display or over HDBaseT via RJ45 for remote displays at distances up to 100 m. The integrated LW3 control engine allows button functions to be programmed for source switching, display power, audio control, and custom automation macros without an external processor. Ethernet provides IP connectivity for room booking system integration, IP display control, and remote monitoring. PoE (IEEE 802.3at) powers the panel from the network infrastructure, removing the requirement for a local 230V or 240V supply at the wall plate. USB 2.0 pass-through supports room peripherals. The white finish matches standard EU electrical wall plates from manufacturers including Schneider, Legrand, and ABB, maintaining interior design consistency in European office and education fit-outs.

Key Features

• EU 86mm Back-Box Format — fits standard continental European electrical wall boxes for consistent integration with local fittings
• White Finish — matches EU-standard white wall plates for visual consistency in European office and education interiors
• Integrated AV Switching — HDMI and USB-C inputs with HDMI and HDBaseT outputs built in, no external switcher required
• No Control Processor Required — embedded LW3 engine handles room automation logic directly on the device
• Capacitive Touch Buttons — programmable for source selection, display control, audio, and custom macros via web interface
• HDBaseT Output to 100 m — single Cat6A cable drives displays at full 4K 60 Hz up to 100 m
• PoE Powered (IEEE 802.3at) — no mains supply at wall plate, reducing electrical installation scope
• LW3 Open Protocol — no licensing fees; configurable via web browser or third-party control drivers
• 4K UHD 60 Hz, HDCP 2.2 — supports full 4K presentation sources and HDCP-protected content
• Ethernet Integration — connects to room booking systems, IP displays, and BMS over standard network infrastructure

Typical Applications

• Corporate boardrooms and conference rooms across continental Europe
• European university and higher education meeting rooms
• Government and public sector meeting facilities in EU member states
• Hotel conference suites and event spaces
• Huddle spaces requiring a single wall-plate AV and control solution
• Healthcare meeting rooms and consultation suites

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What wall back-box does the RAP-B511-EU-W require?

The panel requires a standard EU 86x86mm wall back-box. This is the dominant electrical wall box standard across continental Europe, used for power sockets, light switches, and data outlets by manufacturers including Schneider Electric (Odace, Merten), Legrand (Mosaic), and ABB (Busch-Jaeger).

Is the RAP-B511-EU-W different from the RAP-B511-UK-W?

Yes. The EU model uses the 86x86mm European wall box format, while the UK model uses the UK 2-gang back-box format. The internal electronics and functionality are identical; only the physical housing and fascia dimensions differ to match the respective regional electrical standards.

Does the RAP-B511-EU-W need a 230V supply at the wall?

No. The panel is powered via PoE (IEEE 802.3at) over the Ethernet cable from the network switch. No 230V or other mains supply is required at the wall plate, simplifying electrical installation and reducing the need for a dedicated power circuit at each panel location.

Can I integrate the RAP-B511-EU-W with Microsoft Teams Rooms or Zoom Rooms?

Yes. The panel handles AV switching and display control as the hardware layer, while the Teams Rooms or Zoom Rooms software codec runs on a connected room PC or dedicated appliance. LW3-based control drivers or custom IP commands facilitate integration between the panel and the conferencing software.

How are the button functions configured?

Button behaviour is programmed via the LW3 protocol through a standard web browser pointing at the panel's IP address. No proprietary software client installation is required. Source switching, display macros, audio control, and custom commands are all configured through the web interface.

What is the maximum video resolution?

The RAP-B511-EU-W supports 3840x2160 (4K UHD) at 60 Hz with 4:4:4 colour sampling. HDCP 2.2 is supported for protected content from streaming players and professional video sources.

Where can I purchase the Lightware RAP-B511-EU-W?

The RAP-B511-EU-W is available from Creation Networks at creationnetworks.net, an authorised Lightware reseller supplying commercial AV integrators and end-user procurement teams.
