LightWare PSU-24VP3-220 Spare Power Supply

Product Overview

The Lightware PSU-24VP3-220 is a spare 24V DC power supply delivering up to 9.16A for Lightware Taurus and UCX product series. It carries the highest current rating in the 24V P3 spare PSU family, making it appropriate for fully populated UCX frames or multi-board Taurus configurations with high power draw. Universal AC input (100–240V) with IEC plug. Available from Creation Networks at creationnetworks.net.

Product Description

The PSU-24VP3-220 is the high-capacity spare for Lightware's 24V UCX and Taurus platforms. Where the 160 variant (6.67A) covers smaller or partially populated frames, the 220 (9.16A) supports fully configured systems with maximum board count or accessory load. Holding a spare of the correct current rating on-site is critical: substituting a lower-rated PSU in a high-load configuration risks thermal shutdown or frame instability during high-demand periods.

The 220W output capacity (24V x 9.16A) positions this unit for enterprise AV control rooms, large-venue switching infrastructure, and any UCX/Taurus deployment with heavy concurrent port use. Like all P3 series PSUs, it uses a standard IEC inlet for global compatibility.

Key Features

• 24V DC output at 9.16A (220W nominal)
• Universal AC input: 100–240V, 50/60 Hz
• IEC connector — globally compatible
• Designed for Lightware Taurus and UCX product series
• Highest current-rated spare in the 24V P3 family
• Drop-in replacement — no configuration required

Typical Applications

• Spare PSU for fully populated Lightware UCX frames in enterprise AV installations
• Replacement for Lightware Taurus series equipment in high-load configurations
• Redundancy unit for mission-critical UCX switching in broadcast or command center environments
• New UCX frame builds requiring a second power supply for N+1 redundancy

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What is the difference between the PSU-24VP3-220 and the PSU-24VP3-160?

The PSU-24VP3-220 delivers 9.16A (approximately 220W) versus the PSU-24VP3-160 at 6.67A (approximately 160W). The 220 variant is required for fully populated UCX or Taurus frames with high concurrent port or accessory load. The 160 is sufficient for smaller or partially configured systems.

How do I know which PSU my Lightware UCX frame requires?

Consult the Lightware UCX or Taurus product datasheet for your specific frame model and board configuration. The datasheet specifies maximum power draw and the required PSU current rating. Contact Creation Networks for guidance.

Can I use a lower-rated PSU (PSU-24VP3-160) as a temporary spare?

Not recommended for fully populated frames. A lower-rated PSU may enter thermal protection or cause frame instability under full load. Always match or exceed the specified current rating.

Is this a drop-in replacement with no reconfiguration needed?

Yes. The PSU-24VP3-220 is plug-and-play. No firmware changes, DIP switch settings, or software configuration are required after swapping.

Should I stock a spare PSU before the installed unit fails?

For any mission-critical installation — broadcast, command center, 24/7 operations — yes. Procurement lead time for spare parts can extend downtime unnecessarily. Stocking a spare PSU eliminates that variable.
