LightWare PSU-24VP3-160 Spare Power Supply

Product Overview

The Lightware PSU-24VP3-160 is a spare 24V DC power supply at 6.67A output for Lightware Taurus and UCX product series. It is the mid-range spare PSU in the 24V P3 family — covering smaller UCX frames, partially populated configurations, or Taurus units with moderate power draw. Universal AC input (100–240V) with IEC plug. Available from Creation Networks at creationnetworks.net.

Product Description

The PSU-24VP3-160 covers UCX and Taurus installations where the total system power draw does not approach the 9.16A ceiling of the PSU-24VP3-220. For smaller room deployments — a two- or four-port UCX receiver, a lightly loaded Taurus frame — this unit provides the correct spare without over-specifying the power supply. Matching spare PSU capacity to actual system load is good engineering practice: it avoids running a frame on an under-rated spare during an outage and minimizes unnecessary cost in procurement.

As with all P3 series Lightware PSUs, the unit uses a proprietary DC output connector that mates directly with the Lightware frame's internal power socket. This makes it a drop-in replacement: power down the frame, swap the PSU, power up — no wiring, no modification, no configuration.

Key Features

• 24V DC output at 6.67A (160W nominal)
• Universal AC input: 100–240V, 50/60 Hz
• IEC connector — globally compatible mains plug
• Designed for Lightware Taurus and UCX product series
• Drop-in replacement — proprietary DC connector, plug and play
• Appropriate for smaller or partially populated UCX/Taurus frames

Typical Applications

• Spare PSU for small to medium Lightware UCX frame installations
• Replacement unit for Taurus series devices in lower-load configurations
• Field service inventory for engineers supporting Lightware UCX deployments
• Budget-conscious redundancy for installations where the 220W variant is over-specified

Technical Specifications

Competitor Comparison

Frequently Asked Questions

How do I know if my Lightware UCX frame requires the 160W or the 220W PSU?

Check your UCX or Taurus product datasheet for the maximum power draw at your specific board count and configuration. If total draw is within 160W (6.67A at 24V), the PSU-24VP3-160 is correct. If it exceeds that, specify the PSU-24VP3-220. Contact Creation Networks if you need help with the calculation.

Is this a drop-in replacement or does it require rewiring?

Drop-in replacement. The PSU-24VP3-160 uses the same proprietary DC connector as the original Lightware PSU. Power down the frame, disconnect the old PSU, connect the new one, and power up.

Can this PSU be used temporarily in a frame that normally uses the 220W variant?

Not recommended under full load. At 6.67A, the 160 variant will trip thermal protection or cause instability if the frame is drawing near 9A. As an emergency measure at reduced load, it may function temporarily — but replace it with the correct 220W unit as soon as possible.

Does this PSU require configuration after installation?

No. It is plug-and-play. No firmware, DIP switches, or software configuration required.

What happens if I use a generic 24V power supply instead of this OEM part?

Generic supplies typically have incompatible DC connectors, unvalidated regulation profiles, and will void the Lightware equipment warranty. Using the OEM spare is the only recommended approach for in-warranty equipment.
