Lightware MX2-48x48-HDMI20-A-R MX2 Series HDMI 2.0 Compatible Matrix Router - 91310065

Product Overview

The Lightware MX2-48x48-HDMI20-A-R is a high-density standalone HDMI 2.0 matrix switcher designed for large-scale fixed installations requiring uncompromised 4K UHD signal routing. With 48 inputs and 48 outputs, this HDMI 2.0 matrix router delivers 4K UHD at 60Hz with RGB 4:4:4 colorspace and supports up to 18 Gbps per port — making it a primary choice for broadcast studios, operation centers, and enterprise AV deployments. The R-type chassis includes redundant Neutrik Powercon connectors and ruggedized RS-232 and Ethernet ports, engineered specifically for high-stress, always-on environments. Audio embedding and de-embedding on 16 dedicated Phoenix analog I/O ports allows the MX2-48x48-HDMI20-A-R to consolidate complex signal chains without external audio hardware.

Product Description

The MX2-48x48-HDMI20-A-R is a member of the Lightware MX2 Series, which is purpose-built for installations that demand the highest port density in a standalone HDMI 2.0 matrix switcher format. The unit handles 4K UHD video at 60Hz in full RGB 4:4:4 colorspace and can down-convert to 4:2:0 where bandwidth constraints require it. HDCP 2.2 and HDCP 1.4 are both supported with cross-conversion, ensuring compatibility across a range of source and display hardware generations. The switcher also carries Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, HDR10, HDR12, and Dolby Vision — covering all current high-bitrate audio and HDR formats. Proprietary Lightware technologies including Pixel Accurate Reclocking and Advanced EDID Management are built in and fully accessible via the integrated web interface, removing the need for third-party EDID management tools. Crosspoint switching is controlled via a front-panel rotary jog dial with color display; no direct port-selection buttons are present, but all routing functions remain available through the front panel UI, web interface, RS-232, and Ethernet. The MX2-48x48-HDMI20-A-R also supports 5K resolution at 5120x2160 via HDMI 2.0, operating at 30Hz 4:4:4 or 60Hz 4:2:0, making it viable for ultrawide and simulation display environments.

Key Features

• 48x48 HDMI 2.0 Port Matrix — Full non-blocking crosspoint switching across 48 inputs and 48 outputs at 18 Gbps per port.
• 4K UHD at 60Hz RGB 4:4:4 — Supports resolutions up to 4096x2160 at 60Hz with full colorspace and up to 600 MHz pixel clock.
• 5K Resolution Support — Handles 5120x2160 HDMI 2.0 signals at 30Hz 4:4:4 or 60Hz 4:2:0 for ultrawide display environments.
• HDR10, HDR12, and Dolby Vision — Full HDR format support including Low Latency Dolby Vision for high-dynamic-range display pipelines.
• High-Bitrate Audio Handling — Supports Dolby Atmos, Dolby TrueHD, and DTS-HD Master Audio passthrough embedded in the HDMI stream.
• 16-Port Analog Audio Embedding/De-embedding — Phoenix connector audio I/O on ports 1–16 enables breakout and injection of analog audio without external hardware.
• HDCP 2.2 and 1.4 with Cross-Conversion — Handles mixed HDCP source and display environments with automatic key management and caching.
• Pixel Accurate Reclocking — Proprietary Lightware technology eliminates jitter and signal degradation on long cable runs.
• Advanced EDID Management — Configurable EDID emulation per port, accessible via built-in web interface without additional software.
• Zero Frame Delay Switching — No signal latency introduced during crosspoint switching, critical for live production and control room environments.
• Redundant R-Type Power — Dual Neutrik Powercon True1 connectors (110/220V) with ruggedized RS-232 D-sub 9-pole and Ethercon Ethernet ports.
• 8RU Rack-Mount Chassis — 19-inch rack-mountable with removable rack ears; includes handle pair and power cables as supplied accessories.

Typical Applications

• Broadcast studio signal routing and production switching
• Enterprise operation centers and network operations centers (NOC)
• Government and defense command and control facilities
• Large-format auditorium and multi-purpose room AV distribution
• Training room and all-hands room with high source and display counts
• Fixed-install conference room and boardroom systems requiring 4K signal integrity
• Simulation and visualization environments with ultrawide or multi-screen output

Technical Specifications

Competitor Comparison

Frequently Asked Questions

Does the MX2-48x48-HDMI20-A-R support 4K at 60Hz on all 48 ports simultaneously?

Yes. The unit uses a fully non-blocking crosspoint architecture with 18 Gbps per port, supporting 4K UHD at 60Hz with RGB 4:4:4 colorspace on all 48 inputs and 48 outputs concurrently without bandwidth contention.

Can I route audio independently from video?

The 16 Phoenix analog audio ports (inputs and outputs on ports 1–16) allow audio embedding and de-embedding from the HDMI stream. Audio follows the video crosspoint by default, but the analog I/O ports allow breakout and injection at the port level.

What does the R-Type designation mean?

R-Type indicates a redundancy-hardened version of the chassis. It includes two independent Neutrik Powercon True1 AC mains connectors and reinforced RS-232 and Ethernet ports designed for continuous operation in high-stress AV environments where power redundancy is required.

How is EDID managed across 48 ports?

The MX2-48x48-HDMI20-A-R includes Lightware's Advanced EDID Management, which allows per-port EDID configuration through the built-in web interface. No additional software installation is required — the web UI is accessible directly via the Neutrik Ethercon port.

Is the unit compatible with third-party control systems such as Crestron or AMX?

Yes. The unit supports control via Ethernet (TCP/IP), RS-232, and USB, making it compatible with Crestron, AMX, Extron, and other control systems that communicate via standard serial or IP-based protocols.

Does the MX2-48x48-HDMI20-A-R support HDCP 2.2 content?

Yes. The unit is HDCP 2.2 and HDCP 1.4 compliant with cross-conversion, meaning it can handle sources and displays with different HDCP versions in the same routing matrix.

Where can I purchase the Lightware MX2-48x48-HDMI20-A-R?

The MX2-48x48-HDMI20-A-R is available through Creation Networks at creationnetworks.net. Contact us for volume pricing, integration support, and lead time information.
