Lightware MX-FR80R upgrade MX-FR65R upgrade package up to MX-FR80R ...
Product Overview
The Lightware MX-FR80R upgrade package converts an existing MX-FR65R modular matrix router frame to an MX-FR80R, expanding the crosspoint size from 65x65 to 80x80. This is a factory-applied or field-applied upgrade for organizations that originally specified an MX-FR65R frame and have outgrown its port capacity without wanting to replace the entire chassis. The upgrade retains all existing I/O boards, control configuration, and cabling while delivering the larger 80x80 crosspoint of the MX-FR80R. For broadcast studios, large operations centers, and university AV systems running MX-FR65R infrastructure that has reached capacity, this upgrade provides a cost-effective path to additional routing headroom within the same physical frame.
Product Description
The MX-FR80R is the largest frame size in the Lightware MX series modular router lineup, supporting an 80x80 crosspoint with the full MX I/O board library—including HDMI 1.4 boards with 4K and 3D, DVI-D, dual-link DVI, HDBaseTT with PoE, 3G-SDI, fiber optical boards for up to 2500m runs, and TPS twisted pair extension boards. The upgrade from MX-FR65R to MX-FR80R adds 15 additional input and output slots to the existing frame's routing capacity, using the same board types already deployed. EDID management retains 100 factory presets and 50 user-programmable profiles. Ethernet (10/100Base-TX auto-sensing), RS-232/422, and front-panel LCD crosspoint control are all maintained post-upgrade. Maximum power consumption is 400W. EN 55022 Class B, RoHS compliant, 3-year warranty.
Key Features
- Expands MX-FR65R to MX-FR80R — crosspoint grows from 65x65 to 80x80
- Retains existing I/O boards and cabling — no replacement of installed infrastructure
- 80x80 non-blocking crosspoint — largest MX series frame capacity
- Full MX board compatibility post-upgrade — HDMI 1.4 4K/3D, DVI, HDBaseT, SDI, fiber, TPS
- EDID management preserved — 100 factory + 50 user profiles, EDID v1.3 emulation
- Front-panel LCD maintained — 4x20 character display with crosspoint control keys
- Ethernet and RS-232/422 control — 10/100Base-TX, 9600–115200 baud
- Power consumption max 400W
- EN 55022 Class B and RoHS compliant
- 3-year warranty
Typical Applications
- Broadcast studio
- Government space / operations center
- Auditorium
- All-hands room
- House of worship
Technical Specifications
| Specification | Value |
|---|---|
| Upgrade path | MX-FR65R to MX-FR80R |
| Resulting crosspoint | 80x80 non-blocking |
| EDID memory | 100 factory preset + 50 user programmable |
| EDID emulation | 256-byte Extended EDID v1.3 |
| Front panel | 4x20 character LCD, crosspoint control buttons |
| Ethernet | 10Base-T or 100Base-TX auto-sensing, built-in web |
| RS-232/422 | Selectable, 9600–115200 baud (default 57600), 8N1 |
| Power max | 400W |
| Operating temperature | 0°C to +50°C |
| Compliance | EN 55022 Class B, RoHS |
| Warranty | 3 years |
| SKU | 91110007 |
Competitor Comparison
| Criteria | Lightware MX-FR80R (via upgrade) | Crestron DM-MD32X32 | Extron DXP 88 HDMI | Kramer VS-6464DN-EM |
|---|---|---|---|---|
| Crosspoint size | 80x80 (modular) | 32x32 | 8x8 | 64x64 |
| Field upgrade path | Yes — from MX-FR65R | No | No | No |
| Reuses existing boards | Yes | N/A | N/A | N/A |
| Signal type flexibility | DVI, HDMI 1.4, SDI, fiber, TPS, HDBaseT | HDMI via cards | HDMI 1.4 only | HDMI 2.0 over IP |
| Max I/O per frame | 80x80 | 32x32 | 8x8 | 64x64 |
| Fiber optical boards | Yes — up to 2500m | No | No | No |
| EDID management | 100 factory + 50 user | Yes | Basic | Yes |
| Investment protection | Yes — existing chassis reused | No | No | No |
Frequently Asked Questions
- What exactly is included in the MX-FR80R upgrade package?
- The upgrade package (SKU 91110007) provides the hardware and licensing necessary to expand the MX-FR65R chassis to MX-FR80R crosspoint capacity. All existing I/O boards installed in the frame remain in place and continue to function. Contact Creation Networks for specific installation requirements and any associated labor considerations.
- Do existing I/O boards need to be replaced after the upgrade?
- No. All MX series I/O boards—HDMI 1.4, DVI, HDBaseT, SDI, fiber optical, and TPS boards—remain fully compatible and operational in the expanded MX-FR80R frame after the upgrade.
- Can the MX-FR80R accommodate more board slots than the MX-FR65R?
- Yes. The MX-FR80R supports an 80x80 crosspoint versus the MX-FR65R's 65x65, providing 15 additional input and 15 additional output board positions for expanded port density.
- Is this upgrade available for any other MX frame sizes?
- This specific SKU (91110007) covers the MX-FR65R to MX-FR80R upgrade path. Other upgrade paths within the MX series may be available—contact Creation Networks for the applicable SKU for your current frame configuration.
- Where can I purchase the MX-FR80R upgrade?
- Available directly from Creation Networks at creationnetworks.net.
