Lightware HDMI-TPS-RX87 TPS extender for single CATx cable with Poe - 91540085

Product Overview

The Lightware HDMI-TPS-RX87 is a HDBaseT TPS receiver designed for point-to-point extension of HDMI 2.0 signals over a single CATx cable at distances up to 100 meters. It operates as the receive-side unit in the HDMI-TPS-TX87/RX87 extender pair, accepting HDBaseT input from the transmitter and outputting HDMI 2.0 to a local display. Power over Ethernet (PoE) support means the unit can be powered directly from the transmitter end, eliminating the need for a local power supply at the display.

Available at Creation Networks.

Product Description

The HDMI-TPS-RX87 supports HDMI 2.0b with HDCP 2.2, enabling transport of 4K/60Hz 4:4:4 video along with up to 8-channel audio. The unit passes through Ethernet, RS-232, and IR control signals alongside the video signal — making it suitable for installations where a single CATx run must carry all AV and control traffic. The built-in PoE receiver draws power from the HDBaseT link, so only the TX87 transmitter requires mains power. EDID management is handled locally, and the unit provides status LEDs for link confirmation. The form factor is compact and mountable, suited for behind-display or rack-adjacent installation.

Key Features

• HDMI 2.0b input/output with HDCP 2.2 compliance
• 4K/60Hz 4:4:4 8-bit and HDR support
• HDBaseT extension up to 100m over Cat5e/6/7
• Power over Ethernet (PoE) — powered from transmitter, no local PSU needed
• Bidirectional RS-232 and IR pass-through
• 100Base-T Ethernet pass-through over HDBaseT link
• EDID management with stored EDID support
• Compact chassis with status LED indicators
• Compatible with HDMI-TPS-TX87 transmitter

Typical Applications

• Corporate boardrooms and huddle rooms with ceiling-mounted or wall-mounted displays
• Higher-education lecture halls requiring 4K source distribution to a single remote display
• Digital signage installations where the media player is located in a remote equipment rack
• Healthcare environments needing clean cable runs between control rooms and patient display areas
• Broadcast production facilities extending HDMI from capture equipment to monitoring positions

Technical Specifications

Competitor Comparison

Frequently Asked Questions

Does the HDMI-TPS-RX87 require a separate power supply?

No. The RX87 is a PoE powered device (IEEE 802.3af PD). It draws power from the HDMI-TPS-TX87 transmitter over the HDBaseT cable, so no local mains power is needed at the receiver end.

What cable category is required for 4K/60Hz performance?

Lightware specifies Cat6 or better for full 4K/60Hz 4:4:4 at up to 100 meters. Cat5e may work at shorter distances but Cat6 or Cat7 is recommended for guaranteed performance.

Is the RX87 compatible with third-party HDBaseT transmitters?

The RX87 is designed and tested as a matched pair with the HDMI-TPS-TX87. Interoperability with third-party HDBaseT transmitters is not guaranteed by Lightware and may result in reduced feature availability.

Does it support HDR content?

Yes. The HDMI-TPS-RX87 supports HDR10 and HLG through its HDMI 2.0b interface, provided the source and display also support the relevant HDR format.

Can I pass control signals alongside video?

Yes. The unit passes bidirectional RS-232, IR, and 100Base-T Ethernet signals over the same CATx cable as the video, using the HDBaseT protocol's multi-signal transport.

What is the maximum supported resolution?

4K (3840x2160) at 60Hz with 4:4:4 chroma, 8-bit color depth. For HDR content at 4K/60Hz, 4:2:0 12-bit is also supported.
