Lightware HDMI-TPS-RX86 TPS extender for single CATx cable - 91540087

Product Overview

The Lightware HDMI-TPS-RX86 is a HDBaseT TPS receiver that extends HDMI signals over a single CATx cable from a compatible transmitter. It is the receive-side unit in the HDMI-TPS-TX86/RX86 pair, converting an HDBaseT input back to HDMI output for connection to a display. Unlike the PoE-equipped RX87, the RX86 requires a local power supply, making it the cost-effective choice for installations where a local power outlet is available at the display location.

Available at Creation Networks.

Product Description

The HDMI-TPS-RX86 receives an HDBaseT signal from the paired TX86 transmitter and outputs HDMI to a local monitor or projector. It supports HDMI 2.0 with HDCP 2.2, enabling 4K/60Hz transport. RS-232 and IR control signals travel alongside the video on the same CATx run. The unit does not include PoE, so a separate 12V DC power supply is required at the receiver end. This makes the RX86/TX86 pair a practical option when both ends of the installation have accessible power and a lower overall system cost is the priority. EDID management is supported, and status LEDs indicate link and HDCP state.

Key Features

• HDMI 2.0 output with HDCP 2.2 compliance
• 4K/60Hz support over HDBaseT link
• Extension up to 100m over Cat5e/6/7
• RS-232 and IR control pass-through
• 100Base-T Ethernet pass-through
• EDID management with stored EDID support
• Local power supply required (no PoE) — lower unit cost than RX87
• Compact chassis with status LED indicators
• Compatible with HDMI-TPS-TX86 transmitter

Typical Applications

• Conference rooms and training suites where power is accessible at the display wall plate
• Retail or hospitality digital signage with displays above powered wall outlets
• Educational environments where cost-per-drop is a priority and local power is available
• Fixed installation AV systems where both source and display racks have dedicated power circuits
• Upgrading legacy SDI or analog runs to HDMI over structured cabling infrastructure

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What is the difference between the RX86 and RX87?

The primary difference is PoE support. The RX87 can be powered over the HDBaseT cable from the TX87 transmitter, eliminating the need for a local power outlet at the receiver. The RX86 requires a separate 12V DC power supply at the receiver end. Both units otherwise share the same video and control feature set at a slightly lower price point for the RX86.

What transmitter is the RX86 compatible with?

The HDMI-TPS-RX86 is designed and tested as a matched pair with the HDMI-TPS-TX86 transmitter. Cross-compatibility with the TX87 or third-party HDBaseT transmitters is not guaranteed by Lightware.

Does the RX86 include a power supply?

Yes. A 12V DC external power adapter is included in the box. The unit must be powered locally — it does not accept PoE from the HDBaseT link.

What cable type is recommended?

Cat6 or Cat7 is recommended for reliable 4K/60Hz performance at distances over 50 meters. Cat5e may be used at shorter runs. Avoid unshielded cable runs in areas with high electromagnetic interference.

Can I use the RX86 without RS-232 or IR control?

Yes. The control pass-through features are optional. The unit will transport HDMI video and audio regardless of whether RS-232 or IR devices are connected. Unused control ports do not affect video operation.
