LightWare Finisar 10G SFP+ SM BiDi "B" Finisar 10Gbit SFP+ transceiver  BiDi "B" module (industrial grade) for singlemode fiber

Product Overview

The Lightware Finisar 10G SFP+ SM BiDi "B" is an industrial-grade 10Gbps SFP+ transceiver for singlemode fiber, using Bidirectional (BiDi) technology to transmit and receive over a single fiber strand. It operates as the "B" module in a paired BiDi link — it must be connected to a Finisar 10G SFP+ SM BiDi "A" module at the opposite end. Designed for use with Lightware AV-over-IP infrastructure, particularly with VINX series switches and 10G fiber-connected endpoints. Available from Creation Networks.

Product Description

BiDi transceivers use wavelength-division multiplexing (WDM) to carry TX and RX traffic on different wavelengths over a single fiber strand. This halves the fiber count required between switches and endpoint devices, reducing infrastructure cost and conduit fill in fiber-constrained environments. The "B" module in a BiDi pair transmits on 1330nm and receives on 1270nm, making it the complementary counterpart to the "A" module. Industrial-grade construction ensures reliable operation across a wider temperature range than standard commercial-grade SFP+ modules, appropriate for AV installations in equipment rooms and other variable-environment spaces. These transceivers slot directly into SFP+ cages on Lightware VINX series switches and compatible third-party 10GbE switches.

Key Features

• 10Gbps SFP+ form factor — compatible with standard SFP+ cages
• BiDi technology: single fiber strand carries both TX and RX traffic
• TX wavelength: 1330nm | RX wavelength: 1270nm (pairs with BiDi "A" module)
• Singlemode fiber (SMF) operation
• Industrial grade — extended operating temperature range
• Plug-and-play in SFP+ hosts — no drivers or configuration required
• MSA (Multi-Source Agreement) compliant form factor
• Validated for use in Lightware VINX AV-over-IP 10G infrastructure

Typical Applications

• 10G fiber uplinks between Lightware VINX AV-over-IP switches and core network switches
• Single-fiber inter-building links where fiber pairs are scarce
• Campus AV distribution networks running singlemode fiber backbone
• Data center and server room to AV equipment room 10G fiber connections
• Any 10GbE installation requiring single-fiber BiDi operation on singlemode fiber

Technical Specifications

Competitor Comparison

Frequently Asked Questions

Can this module be used without the matching BiDi "A" module?

No. BiDi transceivers must be used in matched pairs: one "A" module at one end of the fiber, and one "B" module at the other. Mixing two "A" or two "B" modules on the same fiber link will not produce a working connection.

What fiber cable type is required?

Singlemode fiber (OS1 or OS2) with LC connectors. A single fiber strand is sufficient — the BiDi technology carries both directions on one fiber. Standard duplex LC to duplex LC patch cords are also compatible, using only one fiber of the pair.

Is this module compatible with third-party switches?

The module is MSA-compliant and will physically fit any SFP+ cage. However, some vendor-locked switches (notably Cisco) may require a vendor-specific coded module. Confirm compatibility with your switch vendor before ordering. Contact Creation Networks for guidance.

What is the maximum reach of this transceiver?

Up to 10km on OS1/OS2 singlemode fiber at 10Gbps, subject to fiber loss budget. For longer distances, consult the transceiver's optical budget specification and your fiber plant loss measurements.

Do I need one or two of these modules per link?

One BiDi "B" module per link end. A complete single-fiber 10G link requires one BiDi "A" module (part 11800128) and one BiDi "B" module (this product, 11800129) — purchased separately.
