Lightware DP-TPS-TX210 TPS (HDBaseT™) DisplayPort Extender with Local Monitor Out - 91540019

Product Overview

The Lightware DP-TPS-TX210 is an HDBaseT transmitter for DisplayPort sources that extends DP signals up to 100 meters over a single shielded CAT6/7 cable with a local DisplayPort monitor output for presenter confidence monitoring. Designed for corporate boardrooms, engineering workstations, and visualization facilities where DisplayPort is the native source interface, the DP-TPS-TX210 eliminates the need for HDMI adapters or format converters at the source device. RS-232 and IR pass-through enable full control system integration with standard AV automation platforms.

Product Description

DisplayPort is the native video output on most modern workstations, laptops with discrete GPUs, and high-resolution displays — yet the majority of HDBaseT extenders require an HDMI source. The DP-TPS-TX210 resolves this directly by accepting a DisplayPort input and transmitting it natively over HDBaseT, preserving signal quality and eliminating the adapter chain that introduces compatibility issues and signal degradation in professional installations.

The local DisplayPort monitor output allows the source signal to be simultaneously displayed at the transmitter location — useful for presenter stations, podiums, or engineering desks where the operator needs a local view of the content being sent to a remote display. RS-232 and IR pass-through support bidirectional control integration, and the unit communicates with control systems via Lightware's LW3 Ethernet protocol for full status and configuration management.

The DP-TPS-TX210 is available from Creation Networks, an authorized Lightware dealer providing commercial AV solutions across North America.

Key Features

• Native DisplayPort input — accepts DP source directly without requiring HDMI adapters or conversion hardware
• HDBaseT transmission up to 100m — extends DisplayPort over a single shielded CAT6/7 cable
• Local DisplayPort monitor output — provides a simultaneous confidence monitor feed at the transmitter end
• Bidirectional RS-232 pass-through — routes serial commands between the control system and far-end display or source
• IR pass-through — enables IR remote control of devices at the far end via the TPS cable
• LW3 protocol control — Lightware's open Ethernet-based API for configuration and status monitoring
• HDCP compliant — handles protected content over the DisplayPort and TPS links
• Compatible with Lightware TPS receivers — pairs with the TPS receiver family for guaranteed interoperability

Typical Applications

• Engineering and design workstations with native DisplayPort outputs requiring signal extension to wall-mounted displays
• Boardrooms and executive conference rooms where desktop workstations connect via DisplayPort to far-end displays
• Training rooms with instructor workstations using DisplayPort and displays distributed over CAT infrastructure
• Visualization and simulation facilities requiring native DP signal extension without format conversion
• Huddle rooms with DisplayPort-equipped all-in-one PCs or workstations

Technical Specifications

Competitor Comparison

Frequently Asked Questions

Why use the DP-TPS-TX210 instead of a DisplayPort-to-HDMI adapter with an HDMI extender?

Active DP-to-HDMI adapters introduce an additional conversion stage that can cause EDID negotiation failures, HDCP handshake issues, and resolution mismatches. The DP-TPS-TX210 accepts DisplayPort natively, eliminating this layer of complexity and potential failure points.

What DisplayPort versions are supported on the input?

The unit supports DisplayPort 1.1 and 1.2 sources. Multi-Stream Transport (MST) daisy-chaining is not supported; a single direct DisplayPort connection from the source is required.

Does the local monitor output stay active when the TPS link is in use?

Yes. The local DisplayPort monitor output is continuously active regardless of TPS link state.

Can the DP-TPS-TX210 pair with any HDBaseT receiver?

The unit follows the HDBaseT standard and will operate with other compliant receivers. For full feature support including LW3 control and diagnostics, a Lightware TPS receiver is recommended.

Is RS-232 control bidirectional?

Yes. RS-232 pass-through operates bidirectionally, supporting control system commands routed to a display at the far end and status responses returned to the control system.

What resolution is supported over 100 meters?

1080p@60Hz is the standard operating resolution for full 100-meter range. Higher resolutions may be supported at shorter cable runs.

Where can I purchase the DP-TPS-TX210?

Available from Creation Networks, an authorized Lightware dealer in North America.
