Liberty AV E-DPM-M-10F DisplayPort Molded AWM Interconnection Cable, 10 ft

Product Overview

The Liberty AV E-DPM-M-10F is a 10-foot DisplayPort male-to-male AWM cable engineered for commercial AV and IT installations requiring reliable 4K video transmission from DisplayPort-equipped sources. Built with molded strain-relief connectors and AWM (Appliance Wiring Material) rated cable, this DisplayPort cable is suited for AV integration in corporate conference rooms, control rooms, and desktop workstation environments. It delivers full DisplayPort 1.2 bandwidth to support resolutions up to 4K at 60Hz across its 10-foot run.

Product Description

The E-DPM-M-10F is a 10-foot DisplayPort cable from Liberty AV Solutions, designed for AV integrators and IT professionals deploying DisplayPort connections in commercial environments. DisplayPort 1.2 provides up to 21.6 Gbps of bandwidth (HBR2 mode), sufficient to drive 4K Ultra HD displays at 60Hz and support multi-stream transport (MST) for daisy-chaining multiple monitors. The cable features molded, snagless strain-relief boots on both ends that protect the connector latch mechanism and minimize mechanical stress at the termination point during installation routing. The AWM (Appliance Wiring Material) rating indicates the cable meets UL safety standards for internal wiring of appliances and equipment, which is a common requirement for AV equipment cabinet and rack installations. The 10-foot length provides sufficient reach for conference room table-to-display runs, AV rack-to-monitor connections, and flexible desktop workstation setups. Standard DisplayPort locking connector latches on both ends prevent accidental disconnection in vibration-prone or high-traffic environments. The cable is compatible with all DisplayPort 1.2-compliant sources and displays, including those from major commercial AV manufacturers. This cable is a practical component for AV system deployments requiring dependable, specification-compliant DisplayPort interconnects.

Key Features

• DisplayPort 1.2 Compliant — Supports up to 21.6 Gbps bandwidth (HBR2) for 4K/60Hz and multi-stream transport.
• 4K Ultra HD Support — Carries 3840x2160 resolution at 60Hz for commercial display and AV system deployments.
• AWM Rated Cable — Appliance Wiring Material rating meets UL standards for AV equipment cabinet and rack wiring.
• Molded Strain-Relief Connectors — Protects the connector-to-cable junction from mechanical stress during installation and long-term use.
• Locking Connector Latches — Standard DisplayPort locking mechanism prevents accidental disconnection in commercial AV environments.
• Multi-Stream Transport (MST) — Supports daisy-chaining multiple DisplayPort displays from a single source output.
• 10-Foot Length — Covers typical conference room, workstation, and AV rack installation distances.
• Male-to-Male Configuration — Standard DP male connectors on both ends for direct device-to-display connections.

Technical Specifications
