LG WM-LS4-3 – Wall Mount Side Frame includes a pair of Left and Right Vertical Side

Product Overview

The WM-LS4-3 provides the matched left and right vertical side frame rails for a 4-cabinet LMPA or LMPB LED panel wall mount installation. As the outermost load-bearing structural elements of the wall mount assembly, these side frames anchor the display system to the wall surface and support the full weight of a 4-cabinet LED panel array. The WM-LS4-3 integrates with the WM-LC4-3 center frame and compatible WM-LH horizontal bars to deliver a complete, dimensionally matched mounting solution for commercial LED digital signage deployments.

Product Description

The WM-LS4-3 side frame set includes both left and right vertical rails, providing the complete outer structural support for a 4-cabinet LMPA or LMPB LED panel wall mount system. In large-format LED video wall installations, properly engineered side frames are critical — they are the primary interface between the display assembly and the building wall, bearing the full load of the panel cabinets and distributing it to the wall anchors. The WM-LS4-3 rails are dimensioned for the wider footprint of a 4-cabinet configuration, ensuring that the vertical rails reach the correct positions at the outer edges of the display and provide stable support across the full width of the array. Pairing the left and right rails in a single SKU simplifies procurement and guarantees that both frames arrive as a matched set, eliminating the risk of mismatched geometry during installation. AV integrators specifying a 4-cabinet wall mount should combine the WM-LS4-3 with the WM-LC4-3 center frame and WM-LH horizontal bars to form a complete, cabinet-count-matched assembly. The WM-LS4-3 is designed for permanent commercial digital signage installations in corporate, retail, hospitality, institutional, and large-venue environments.

Key Features

• Matched Left/Right Rail Pair — Includes both left and right vertical side frames in a single SKU, ensuring matched geometry and streamlined procurement.
• Primary Structural Load-Bearer — Side frames anchor directly to the wall and carry the full weight of the 4-cabinet LED panel assembly.
• 4-Cabinet Configuration — Dimensioned specifically for wall mount systems using 4 LMPA or LMPB LED panel cabinets.
• Modular System Integration — Pairs with WM-LC4-3 center frame and compatible WM-LH horizontal bars for a complete matched wall mount system.
• LMPA/LMPB Compatibility — Validated for use with LMPA and LMPB series LED panel cabinet systems.
• Commercial-Grade Construction — Built to withstand the structural demands of large-format, permanent commercial LED video wall installations.

Typical Applications

• Large corporate lobby and reception area LED video walls
• Retail flagship and large-format digital signage installations
• Hotel ballroom and large hospitality venue display walls
• Command and control room video wall systems
• Convention center and large event venue digital signage
• Airport, transit, and large public venue display installations

Technical Specifications

Frequently Asked Questions

Does the WM-LS4-3 include both the left and right side frames?

Yes. The WM-LS4-3 includes both left and right vertical side frame rails as a matched pair in a single purchase.

What other components are required for a complete 4-cabinet wall mount system?

A complete 4-cabinet wall mount requires the WM-LS4-3 side frames, the WM-LC4-3 center frame, and the appropriate WM-LH horizontal bars. Contact Creation Networks to confirm the full component list for your installation.

Can the WM-LS4-3 be used with cabinets other than LMPA and LMPB?

This product is validated for LMPA and LMPB series cabinets. Use with other LED panel cabinet types is not confirmed by the manufacturer.

Is professional installation required for this product?

Yes. Side frames are primary structural elements in a video wall installation. Professional AV installation by qualified personnel is required to ensure safe and proper performance.

What wall surface types are compatible?

Compatibility with wall surface types (concrete, masonry, steel stud, wood framing) depends on the anchoring hardware and installation methods used. Consult a qualified AV integrator or structural engineer for site-specific guidance.

What warranty does this product carry?

Warranty terms are provided by the manufacturer. Contact Creation Networks for current warranty details on the WM-LS4-3.
