LG WM-LS3-3 – Wall Mount Side Frame includes a pair of Left and Right Vertical Side

Product Overview

The WM-LS3-3 provides the matched left and right vertical side frame rails for a 3-cabinet LMPA or LMPB LED panel wall mount system. As the primary lateral structural elements of the wall mount assembly, these side frames anchor the display to the wall at both outer edges and carry the load of the full 3-cabinet panel array. The WM-LS3-3 integrates with the WM-LC3-3 center frame and WM-LH3-3 horizontal bars to form a complete, dimensionally matched mounting system for commercial LED digital signage installations.

Product Description

The WM-LS3-3 side frame set delivers the left and right vertical rails required for the outer structural support of a 3-cabinet LMPA or LMPB LED panel wall mount. In a 3-cabinet LED video wall installation, the side frames are anchored to the wall surface and bear the primary load of the display assembly, transferring weight safely to the building structure. The vertical rail geometry is designed to align precisely with the attachment points of LMPA and LMPB panel cabinets in a 3-cabinet configuration, ensuring correct positioning and structural integrity throughout the installation. Packaging the left and right rails as a matched pair simplifies procurement and eliminates the risk of mismatched components on site. AV integrators building a complete 3-cabinet wall mount will also need the WM-LC3-3 center frame and WM-LH3-3 horizontal bars. All WM-L series components are cabinet-count-specific, so specifying all three components from the -3 variant ensures full dimensional compatibility across the assembly. The WM-LS3-3 is designed for permanent commercial LED digital signage wall installations in a wide range of corporate, retail, hospitality, and institutional settings.

Key Features

• Matched Left/Right Rail Pair — Includes both left and right vertical side frames in a single SKU for simplified procurement.
• Primary Load-Bearing Support — Side frames anchor to the wall surface and carry the full weight of the 3-cabinet LED panel assembly.
• 3-Cabinet Configuration — Dimensioned specifically for wall mount assemblies using 3 LMPA or LMPB LED panel cabinets.
• Modular System Integration — Designed to pair with WM-LC3-3 center frame and WM-LH3-3 horizontal bars for a complete matched assembly.
• LMPA/LMPB Compatibility — Validated for LMPA and LMPB series LED panel cabinet systems.
• Commercial-Grade Construction — Engineered to meet the load and longevity requirements of permanent commercial digital signage installations.

Typical Applications

• Corporate boardroom and executive conference room LED video walls
• Large-format retail digital signage wall installations
• Hotel lobby and event venue display walls
• Control room and operations center video wall systems
• Higher education auditorium and lecture hall displays
• Airport and transportation hub digital signage

Technical Specifications

Frequently Asked Questions

Does the WM-LS3-3 include both side frames?

Yes. The WM-LS3-3 includes both the left and right vertical side frame rails as a matched pair, providing the complete outer structural support for a 3-cabinet wall mount installation.

What additional components are needed for a complete 3-cabinet wall mount?

A complete 3-cabinet wall mount system requires the WM-LS3-3 side frames, WM-LC3-3 center frame, and WM-LH3-3 horizontal bars. Contact Creation Networks to confirm the full bill of materials for your project.

Can the WM-LS3-3 be used with cabinet types other than LMPA and LMPB?

The WM-LS3-3 is validated for LMPA and LMPB series cabinets. Compatibility with other panel types is not confirmed by the manufacturer.

What is required to anchor the side frames to the wall?

Wall anchoring requirements depend on the wall construction type (concrete, steel stud, wood framing, etc.). A qualified AV integrator or structural engineer should assess the installation surface before proceeding.

Is professional AV installation necessary?

Yes. LED video wall side frames are primary structural elements. Professional installation by trained AV personnel is required for safety and proper performance.

What warranty applies to the WM-LS3-3?

Warranty terms are provided by the manufacturer. Contact Creation Networks for current warranty information on this product.
