LG Ultra Light Series GSCD069-GN2 6.94mm Pixel Pitch LED Signage Display Cabinet
LG Ultra Light Series GSCD069-GN2 6.94mm Pixel Pitch LED Signage Display Cabinet is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
LG Ultra Light Series GSCD069-GN2 6.94mm Pixel Pitch LED Signage Di...
Product Overview
The LG GSCD069-GN2 is a 6.94 mm pixel-pitch Ultra Light outdoor LED signage cabinet for high-brightness exterior video walls. It delivers a 5,000-nit calibrated brightness with 16-bit color and HDR10 support, in a lightweight cabinet that reduces structural load. An IP65-rated weatherproof front and back allow stable outdoor operation, and a modular PDU eases maintenance. It runs webOS 4.0 with HDMI, USB, and Ethernet connectivity.
Product Description
This GSCD-series cabinet carries a 6.94 mm pixel pitch (0.27 inch) with a 144 x 72 resolution on an LCD-class LED panel, measuring 39.4 inches wide by 19.7 inches high by 3.3 inches deep and weighing approximately 22.93 lb. Brightness is rated at 5,000 nits with 16-bit color depth and a 6,000:1 dynamic contrast ratio, supporting HDR10. The IP65 weatherproof front and back design keeps operation stable across weather conditions, and front or rear serviceability adds installation flexibility. A 90-degree corner option lets the wall deliver content from corner positions, and the modular PDU detaches for fast maintenance. Powered by an LG high-performance system controller, the GSCD series works with LG SuperSign CMS, LED Assistant, and ConnectedCare. Input voltage is auto-ranging across 120 V and 230 V AC.
Key Features
- 6.94 mm pixel pitch — resolution suited to outdoor viewing distances.
- 5,000-nit brightness — strong daylight visibility for exterior signage.
- IP65 weatherproof — front and back sealed for stable outdoor operation.
- Ultra Light cabinet — reduces structural load for rooftop and facade installs.
- 16-bit color with HDR10 — high color depth and dynamic range outdoors.
- Front or rear service — flexible maintenance access; modular detachable PDU.
- 90° corner option — delivers content from corner installations.
- LG software compatible — SuperSign CMS, LED Assistant, ConnectedCare.
Typical Applications
The GSCD069-GN2 is a building block for outdoor LED video walls on building facades, rooftops, transit hubs, stadiums, and commercial exteriors where 5,000-nit brightness and weatherproofing are required. Its IP65 rating suits exposed installations, the lightweight cabinet eases large rooftop screens, and the 90-degree corner option supports corner and column-mounted exterior displays.
Technical Specifications
| Specification | Value |
|---|---|
| Model (MPN) | GSCD069-GN2 |
| Series / Line | GSCD, Ultra Light |
| Pixel Pitch | 6.94 mm (0.27") |
| Resolution | 144 x 72 |
| Brightness | 5,000 nit |
| Color Depth | 16-bit |
| Dynamic Contrast Ratio | 6,000:1 |
| HDR | HDR10 |
| Dimensions (W x H x D) | 39.4" x 19.7" x 3.3" |
| Weight (approx.) | 22.93 lb |
| IP Rating | IP65 (front and back) |
| Operating System | webOS 4.0 |
| Inputs/Ports | HDMI, USB, Ethernet |
| Input Voltage | 120 V / 230 V AC |
Specifications sourced from LG vendor data. Unlisted values are omitted rather than estimated.
FAQ
Is it weatherproof?
Yes. The front and back are IP65 certified, allowing stable operation across weather conditions.
How bright is it?
It is rated at 5,000 nits, suited to daylight outdoor visibility.
Can it be installed on a corner?
Yes. A 90-degree corner option lets it deliver content from corner positions.
Is it a standalone display?
No. It is a cabinet building block for a larger outdoor wall; contact Creation Networks to size a complete configuration.
