LG LSCB012-RKR – LSCB DVLED P1.2 Ultra Slim SMD R Mitre Cut Cabinet 800Nits 600x337.5x34

Product Overview

The LG LSCB DVLED P1.2 Ultra Slim R Mitre Cut cabinet is a fine-pitch direct-view LED cabinet designed as the right-side edge panel in angled and corner video wall configurations. At 1.25mm pixel pitch with an 800-nit brightness output and an ultra-slim cabinet profile, this cabinet brings the LSCB series' architectural integration advantage to corner and angled display geometries. The precision right mitre-cut edge enables a clean corner join when the display transitions around a right-side angle, pairing with the L mitre-cut variant on the adjacent surface for a complete corner configuration.

Product Description

The LSCB series is defined by its ultra-slim cabinet depth of approximately 34–41mm, which allows it to be installed in architectural environments where the depth of a conventional LED cabinet would be impractical. The R mitre-cut edge extends this capability to corner positions, allowing the slim-profile display to wrap around a right-side corner without introducing visible gaps or depth discontinuities at the edge.

In a typical corner installation, the LSCB012-RKR is used as the right-side termination panel. The angled edge creates a precise join with the facing surface, which may be an adjacent flat LSCB cabinet array, a matching L mitre-cut cabinet, or an architectural surface. This supports display configurations including 90-degree corner wraps, angled display alcoves, and V-shaped walls.

The direct-view LED backlight technology delivers a high-contrast, high-brightness image at 800 nits, suitable for commercial indoor environments with moderate ambient lighting. The 1.25mm pixel pitch is appropriate for close-range viewing at 4–6 feet, covering executive boardroom, command center, and premium digital signage applications. The 600 x 337.5 x 34mm cabinet format maintains the standard 16:9 aspect ratio used across the LSCB flat cabinet series.

Key Features

• 1.25mm Pixel Pitch — Fine pixel density for close-range indoor viewing at approximately 4–6 feet.
• Ultra-Slim Cabinet Depth — Approximately 34mm total depth for flush architectural integration at corner positions.
• R Mitre Cut Edge — Precision right-side angled edge for clean corner joins in angled display configurations.
• 800-Nit Brightness — Higher output than standard 600-nit indoor cabinets for moderate ambient lighting environments.
• Direct-View LED Backlight — True direct-view LED architecture delivering high contrast and brightness uniformity.
• 16:9 Cabinet Aspect Ratio — Standard aspect ratio for straightforward content and grid layout.
• Front Service Access — Module servicing accessible from the front face without full cabinet removal.
• Commercial Indoor Rated — Designed for permanent commercial interior deployment.

Typical Applications

• Corporate lobby right-side corner video wall panels
• Executive boardroom angled display corners
• Architectural feature wall corner transitions
• High-end retail right-side corner digital signage
• Broadcast studio angled background right-side panels
• Command center multi-surface display corners
• Hospitality feature wall corner configurations

Technical Specifications

Frequently Asked Questions

What is the correct pairing for the LSCB012-RKR in a corner installation?

The LSCB012-RKR (R mitre-cut) is placed on the right wall surface and paired with the LSCB012-RKL (L mitre-cut) on the left wall surface to form a complete 90-degree corner join.

Does the ultra-slim depth apply to the mitre-cut edge as well?

Yes. The mitre-cut edge is precision-machined to maintain the slim profile at the corner join, preserving the flush aesthetic of the LSCB series all the way to the display edge.

What viewing distance is recommended for 1.25mm pixel pitch?

Optimal viewing starts at approximately 4–6 feet, making this cabinet appropriate for boardrooms, executive briefing centers, close-proximity digital signage, and command center displays.

Is a video processor required?

Yes. A compatible LED video processor is required to drive the cabinet array. Creation Networks can assist with processor selection and system design.

Can the R mitre-cut cabinet be combined with flat LSCB P1.2 cabinets?

Yes. Mitre-cut cabinets are dimensionally compatible with flat LSCB cabinets in the same series and can be combined in a single installation.

What warranty is provided?

LG commercial LED products include LG's standard commercial warranty. Contact Creation Networks for current terms and support options.
