LG LSCB012-RKL – LSCB DVLED P1.2 Ultra Slim SMD L Mitre Cut Cabinet...
Product Overview
The LG LSCB DVLED P1.2 Ultra Slim L Mitre Cut cabinet is a fine-pitch direct-view LED cabinet engineered for angled and corner video wall configurations in architecturally sensitive installations. With a 1.25mm pixel pitch, 41mm edge depth, and a precision left mitre-cut edge, this cabinet allows the ultra-slim LSCB display system to transition around a left-side corner without visible gaps or depth discontinuities. HDR content support and IP30 rating confirm its suitability for premium commercial interior environments.
Product Description
The L mitre-cut configuration on this LSCB cabinet enables the left edge to form a clean angular join when the display transitions around a corner or meets an adjacent surface at an angle. The ultra-slim 41mm depth is maintained at the mitre edge, ensuring that the corner transition does not introduce additional visible depth at the join point — a common challenge with conventional LED cabinets at corner positions. This cabinet is designed to be paired with an R mitre-cut cabinet (LSCB012-RKR) on the facing surface to complete a full 90-degree or custom-angle corner join.
The LSCB series' defining characteristic is its 41mm edge depth, which allows the display to be installed in architectural spaces where conventional LED cabinet depth is prohibitive. The L mitre-cut variant extends this capability to corner and angled geometries, enabling curved, angled, and multi-surface display configurations within the same slim-profile product family.
HDR10 and standard HDR support expands the display's dynamic range capability for premium content applications. IP30 rating confirms the cabinet is built for standard commercial interior conditions. Front service access allows LED module replacement without full cabinet removal.
Key Features
- 1.25mm Pixel Pitch — High pixel density for close-range viewing at approximately 4–6 feet.
- 41mm Ultra-Slim Edge Depth — Slim profile maintained at the mitre edge for clean corner integration.
- L Mitre Cut Edge — Precision left-side angled edge for corner joins in angled and multi-surface display configurations.
- 800-Nit Brightness — Higher output for spaces with moderate ambient lighting.
- HDR10 Support — High-dynamic-range content reproduction for premium visual applications.
- IP30 Rated — Rated for standard interior commercial environments.
- Front Service Access — LED module servicing from the front face without cabinet removal.
- 16:9 Cabinet Aspect Ratio — Standard aspect ratio consistent across the LSCB full cabinet series.
Typical Applications
- Corporate lobby corner-wrap ultra-slim video walls
- Executive boardroom angled display panels
- Architectural feature wall corner transitions
- High-end retail corner digital signage
- Broadcast studio angled background configurations
- Hospitality corner feature displays
- Command center multi-surface display arrays
Technical Specifications
| Specification | Value |
|---|---|
| SKU | LSCB012-RKL |
| Pixel Pitch | 1.25 mm |
| Brightness | 800 nit |
| Cabinet Dimensions | 600 x 337.5 x 34 mm |
| Edge Depth | 41 mm |
| Edge Configuration | L Mitre Cut |
| IP Rating | IP30 |
| HDR Support | HDR10 |
| Category | Indoor Direct-View LED Cabinet |
Frequently Asked Questions
- How does the L mitre-cut work with the ultra-slim LSCB cabinet depth?
- The L mitre-cut edge is precision-machined to maintain the 41mm depth profile at the corner join, ensuring the slim aesthetic is preserved all the way to the edge. This avoids the visible depth step that can occur at corner positions with thicker conventional cabinets.
- What cabinet is paired with the LSCB012-RKL to complete a corner?
- The LSCB012-RKL (L mitre-cut) pairs with the LSCB012-RKR (R mitre-cut) to form a complete corner join. The L mitre-cut cabinet is placed on the left wall surface and the R mitre-cut on the right wall surface.
- Is HDR required for this display to function?
- No. The display operates normally with standard SDR content. HDR10 support is available when an HDR-capable source and processor are used.
- Is a video processor required?
- Yes. A compatible LED video processor is required. Contact Creation Networks for processor and system design recommendations.
- What warranty is included?
- LG commercial LED products include LG's standard commercial warranty. Contact Creation Networks for current terms.
- Can this cabinet be combined with flat LSCB P1.2 full cabinets?
- Yes. The mitre-cut cabinets are designed to integrate with flat full cabinets within the LSCB series in the same installation.
