LG LSCB-F163C – LSCB DVLED P1.8 163" 1920X180 SMD 800Nits 6X6 Indoor Bundle

Product Overview

The LG LSCB DVLED P1.8 163" indoor LED bundle delivers 1920x1080 Full HD resolution on an SMD panel array at 800 nits of brightness in a 6x6 cabinet configuration, making it one of the brighter standard indoor LED configurations in the LSCB VERSATILE family. This complete bundle includes LED panels, a 4K LG controller, spare modules, spare boards and parts, a service tool, and LG webOS for onboard content management and multi-view display. At 163 inches diagonal, this display is suited to large conference rooms, auditoriums, corporate lobbies, and command center environments.

Product Description

The LSCB-F163C extends the LSCB VERSATILE series to the 163-inch scale, providing a 6x6 cabinet array with 800 nit peak brightness that exceeds the 500-600 nit range common in competitive indoor LED configurations. Higher brightness is particularly valuable in lobby and atrium environments where ambient light levels are elevated, as well as in applications requiring vivid video playback and high-contrast data visualization.

Integrated LG webOS provides an onboard content management platform with an intuitive on-screen user interface, remote control for initial setup and ongoing adjustments, and an ambient-light sensor that automatically adjusts display brightness in response to changing room lighting conditions. The ambient-light sensor is a practical feature for lobby and retail installations where lighting conditions vary throughout the day. The onboard CMS includes 3.6GB of flash storage for local content scheduling and playback, reducing dependency on external media players for simple signage deployments.

Screen sharing via Miracast and WiDi enables wireless content mirroring from laptops and mobile devices, supporting impromptu presentations in conference room environments without requiring wired HDMI connections. The webOS Quad Core SoC enables simultaneous execution of multiple applications and multi-view display configurations, allowing operators to show multiple content windows on the single display surface.

The bundle includes 2% spare LED modules, spare boards and parts, and a service tool, providing a complete post-installation maintenance kit for long-term system support.

Key Features

• 800 Nit Brightness — Above-standard brightness for enhanced visibility in high ambient light environments such as lobbies and atriums.
• 6x6 Cabinet Configuration — 36-cabinet array delivering a 163-inch diagonal indoor LED display.
• LG webOS Onboard — Integrated smart signage platform with on-screen UI, remote control, and ambient-light sensor for automatic brightness adjustment.
• Onboard CMS with 3.6GB Storage — Local content scheduling and playback without requiring an external media player for standard signage applications.
• Screen Sharing via Miracast and WiDi — Wireless content mirroring from laptops and mobile devices for conference room presentations.
• Quad Core SoC — Multi-task processing supports multi-view display configurations and simultaneous application execution.
• Complete Bundle — Includes LED panels, 4K LG controller, 2% spare modules, spare boards and parts, and service tool.
• 1920x1080 SMD Indoor LED — Full HD resolution on standard SMD panel construction for reliable long-term display performance.

Typical Applications

• Corporate lobby and reception area digital signage
• Large conference room and boardroom display
• Auditorium and house of worship presentation screen
• Command center and operations center visualization
• Retail flagship store display installation
• Broadcast studio background display

Technical Specifications

Frequently Asked Questions

What content management capabilities does the onboard webOS provide?

The integrated webOS CMS supports local content storage (3.6GB flash), scheduled playback, and connection to LG SuperSign CMS for multi-display network management. The on-screen UI and remote control simplify setup and day-to-day operation without requiring a separate media player for standard signage content.

Does the ambient-light sensor work automatically?

Yes. The ambient-light sensor monitors room lighting levels and automatically adjusts display brightness to maintain appropriate image quality and energy efficiency as lighting conditions change throughout the day.

What devices support screen sharing via Miracast and WiDi?

Miracast is supported by most Windows laptops and Android devices. WiDi (Wireless Display) is an Intel technology supported by Intel-equipped Windows computers. Both protocols enable wireless screen mirroring without requiring HDMI cables for presentations.

What AV control systems are compatible with the LSCB-F163C?

LG LSCB series displays support LAN and RS-232 control compatible with Crestron, AMX, Extron, and other professional AV control platforms. Verify specific driver availability with your control system integrator.

What warranty is provided?

LG commercial DVLED displays carry a 3-year limited warranty. Contact Creation Networks at creationnetworks.net for warranty documentation and extended service plan options.

What is included in the complete bundle?

The bundle includes LG direct-view LED panels in a 6x6 configuration, a 4K LG LED system controller, 2% spare LED modules, spare boards and parts, and a service tool for post-installation maintenance.
