LG LSCA-I230F Digital Signage Display - 230" LCD - 10x3 Video Wall
LG LSCA-I230F Digital Signage Display - 230" LCD - 10x3 Video Wall is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
LG LSCA-I230F Digital Signage Display - 230" LCD - 10x3 Video ...
Product Overview
The LG LSCA-I230F is a 230" indoor LED scoreboard video wall configured as a 10x3 array of direct view LED cabinets. With a 3.9mm pixel pitch and 1000-nit brightness, this indoor signage display is purpose-built for arenas, gymnasiums, and large indoor venues where a bright, large-format scoreboard or video board is needed.
Product Description
Part of LG's Essential LSCA series, the LSCA-I230F combines 30 direct view LED cabinets into a single 230" canvas measuring 196.8" wide by 118.1" high. The 3.9mm pixel pitch is matched to the longer viewing distances of indoor sports and event venues, and the 1000-nit brightness keeps scores and content legible under arena lighting. Mount and trim are not included and must be specified for the structure. Browse comparable systems in the full LG commercial display range.
Key Features
- Indoor scoreboard format — Purpose-built for arenas and large indoor venues.
- 3.9mm pixel pitch — Matched to long indoor viewing distances.
- 1000-nit brightness — Legible under bright arena lighting.
- 10x3 array — 30 direct view LED cabinets form a single 230" canvas.
- Large active area — 196.8" wide by 118.1" high.
Typical Applications
- Arenas & stadiums (indoor) — Center-hung or end-wall scoreboards and video boards.
- Gymnasiums & field houses — Scores, stats, and live content.
- Auditoriums — Large-audience content.
- Convention & event centers — Large-format indoor signage.
- Houses of worship — Large-venue worship and event content.
Technical Specifications
| Specification | Detail |
|---|---|
| Manufacturer / Brand | LG Electronics |
| Model (MPN) | LSCA-I230F |
| Product series | LSCA (Essential) |
| Diagonal size | 230" |
| Resolution | 1280 x 768 |
| Pixel pitch | 3.9 mm |
| LED type | Single SMD, Direct View LED |
| Brightness | 1000 nit |
| Video wall configuration | 10 x 3 (30 screens) |
| Active area (W x H) | 196.8" x 118.1" |
| Mount & trim | Not included |
| Environment | Indoor |
Specifications sourced from LG vendor data. Unlisted values are omitted rather than estimated.
Frequently Asked Questions
Is this designed as a scoreboard?
Yes. LG classifies the LSCA-I230F as an indoor scoreboard wall, suited to arenas, gyms, and large indoor venues.
Does it include a mount?
No. Mount and trim are not included and must be specified for the structure, including any center-hung rigging.
What viewing distance suits the 3.9mm pitch?
The 3.9mm pitch is matched to the long viewing distances of arenas and large indoor venues.
How does it integrate with our AV system?
As a configured 10x3 array, it requires a compatible LED controller/processor and signal distribution. Contact Creation Networks to confirm the workflow.
What warranty and support apply?
Covered by LG's commercial warranty and service programs. Contact Creation Networks for current terms and installation support.
